1101-23
[return to Table of Contents]
TWISTLOCKS – CHASSIS TYPE
NON-RETRACTABLE w/ LIGHT HOLES
CHASSIS

7" MODEL 1101-3817-LP-L
178 MM
MODEL 1101-3817-LP-R
3-1/2" 3-1/2" 7-1/4"
89 MM 89 MM 184 MM w/ Low-profile Head

3-3/4"
95 MM
MODEL 1101-3817-LP-L MODEL 1101-3817-LP-R
for Rear Roadside for Rear Curbside
(& Front Curbside if 20') (& Front Roadside if 20') 1101
3-1/2" 2 Light Holes 1 Light Hole
89 MM 1101-3817-LP-L/R Twistlocks
FINISH: PRIMER FINISH: PRIMER
WEIGHT: 24.3 LBS / 11 Kg WEIGHT: 24.7 LBS / 11.2 Kg are the same as 1101-3817-L/R
Twistlocks except Pin Design.
7/8"
22.3 MM
1-1/4"
32 MM

1/2"
I.D. 2-5/16" 12 MM 4-3/16" I.D. 2-5/16" 6-7/16"
Ø59 MM 4-3/16" 107 MM Ø59 MM 163 MM
107 MM
5-9/16"
140.5 MM
11/16" / 17 MM

MODEL 1101-3817-LP-L is shown dimensioned. • Low-profile Pin Head works w/ low-clearance corner
MODEL 1101-3817-LP-R is the mirror opposite (w/ only one light hole). fittings on ALL 53' containers in U.S. & Canadian markets
• Cast steel Housing & forged steel Pin
• Meets AAR specifications for Rail use
EXPLODED VIEW
• Easy-to-operate Gravity Latch
• Angled corner for Side & Rear Light visibility

1105-3817-2-LP
PIN MODEL 1110-8400
1110-4581
DETENT SPRING
7.5 mm x 15.5 mm x 1.5 mm 1110-3706-19R LIGHT HOLE PLUG
LATCH SPRING Weld-on
for 1101-3817-LP-L
1110-4562 1110-3706-19L I.D. 3/4"
LATCH SPRING
DETENT BALL for 1101-3817-LP-R O.D. 2-5/8" Ø19 MM 3/8"
Ø66 MM 9 MM
1110-4503 CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
6101-4621 GREASE FITTING MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER
SET SCREW WEIGHT: 0.3 LBS / 0.136 Kg
1110-4632
1109-3817-1-L HEX NUT, I.D. 3/16" MODEL 1110-8674
HOUSING NYLOC Ø4.8 MM
for 1101-3817-LP-L 5/16"-18 TPI x 3 HOLES LIGHT HOLE PLUG
1109-3817-1R Bolt-on
HOUSING
for 1101-3817-LP-R
I.D. 3/4"
Ø19 MM
O.D. 3-1/8" 1/8"
Ø79.4 MM 3.5 MM
1108-3817-18
LATCH CONVERTS Ø2-5/16" LIGHT HOLE TO Ø3/4"
1110-4769-G8 1110-4631-G5 MATERIAL: STEEL FINISH: WELDABLE PRIMER
HEX BOLT 1107-3206-4 1110-4511-J
HANDLE HEX NUT HEX BOLT WEIGHT: 0.28 LBS / 0.127 Kg

904-696-0010
E-mail: sales@buffersusa.com
1101-23 9/23/22
