TWISTLOCKS – CHASSIS TYPE
NON-RETRACTABLE w/ LIGHT HOLES
CHASSIS

7"
178 MM MODEL 1101-1206-L
3-1/2" 3-1/2" MODEL 1101-1206-R
89 MM 89 MM

3-3/4"
95 MM
7-1/4"
184 MM
1101 3-1/2"
89 MM

MODEL 1101-1206-L MODEL 1101-1206-R
1-3/16" for Rear Roadside for Rear Curbside
30 MM
1-1/4" (& Front Curbside if 20') (& Front Roadside if 20')
32 MM 6-3/16" 3 Light Holes 3 Light Holes
156.5 MM
FINISH: WELDABLE PRIMER
WEIGHT: 21.6 LBS / 10.2 Kg
I.D. 2-5/16" I.D. 2-5/16"
Ø59 MM 5-1/2" Ø59 MM 4-1/4"
140.5 MM 107 MM • Cast steel Housing & forged steel Pin
• Meets AAR specifications for Rail use
• Easily changed from left-hand to right-hand with
no extra parts
O.D. 5/8" • 3 Light Holes in Housings for added flexibility
Ø16 MM • Unused Light Holes can be blanked off with Plugs
MODEL 1101-1206-R is shown dimensioned.
MODEL 1101-1206-L is the mirror opposite (except for housing). shown below, or others shown on pg. 1110-5
• Dual Grease Fittings
• Ledges extended to protect Lights
EXPLODED VIEW
1110-4502 MODEL 1110-8400
DETENT SPRING
MODEL 1110-8400-MOD
8400 shown
1105-1131-2 dimensioned LIGHT HOLE PLUG, Weld-on
PIN 1110-4501 I.D. 3/4"
DETENT BALL Ø19 MM
(2 pcs.)

8400 converts
O.D. 2-5/8" 3/8" Ø2-5/16" Light 8400-MOD
eliminates
1105-1131-29 Ø66 MM 9 MM Hole to Ø3/4" Light Hole
PIN SLEEVE
1110-4503 MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER
GREASE FITTING 1110-1131-6-4 8400 WEIGHT: 0.3 LBS / 0.136 Kg
(2 pcs.) HANDLE POSITIONER 8400-MOD WEIGHT: 0.33 LBS / 0.15 Kg
THINNER HANDLE
POSITIONER
1109-1206-1 ON EARLY MODELS MODEL 1110-8674
HOUSING approx. 5/32"/4mm thick I.D. 3/16" LIGHT HOLE PLUG
Ø4.8 MM
x 3 HOLES Bolt-on
1110-1131-6-9
HANDLE POSITIONER
approx. 3/8"/9mm thick
1110-4505 LOCK NUT
I.D. 3/4"
1110-4504-G5 HEX BOLT Ø19 MM
1107-1131-4 O.D. 3-1/8" 1/8" Converts Ø2-5/16"
HANDLE Ø79.4 MM 3.5 MM Light Hole to Ø3/4"
1110-4508-G5 HEX BOLT
1110-4505
1108-1131-18 LOCK NUT MATERIAL: STEEL FINISH: WELDABLE PRIMER
LATCH WEIGHT: 0.28 LBS / 0.127 Kg
