Page 102 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1101-26
[return to Table of Contents]
TWISTLOCKS – CHASSIS TYPE
NON-RETRACTABLE w/ LIGHT HOLES
HEAVY DUTY for SHALLOW CORNER CASTINGS
CHASSIS

7" ABS LIGHT MODEL 1101-3406-ABS-L
178 MM HOLE
3-1/2" 3-1/2" MODEL 1101-3406-L
89 MM 89 MM MODEL 1101-3406-R

3-3/4"
95 MM
7-1/4"
184 MM
1101 MODEL 1101-3406-ABS-L
3-1/2" for Rear Roadside
89 MM
(& Front Curbside if 20')
3 Light Holes
FINISH: WELDABLE PRIMER
3/4"
19 MM WEIGHT: 26.4 LBS / 11.98 Kg MODEL 1101-3406-L MODEL 1101-3406-R
for Rear Roadside for Rear Curbside
4-1/4" (& Front Curbside if 20') (& Front Roadside if 20')
1-1/4" 107 MM 2 Light Holes 2 Light Holes
32 MM
FINISH: WELDABLE PRIMER
WEIGHT: 26.8 LBS / 12.11 Kg
I.D. 2-5/16"
Ø59 MM 5-9/16"
141.5 MM
• Heavy-duty cast steel Housing & forged steel Pin
• Meets AAR specifications for Rail use
• Easy-to-operate Gravity Latch
• Unused Light Holes can be blanked off with Plugs
6-3/8"
MODEL 1101-3406-L is shown dimensioned. 162 MM shown below, or others shown on pg. 1110-5
MODEL 1101-3406-R is the mirror opposite. • Ledges extended to protect Lights
• Fits most shallow Corner Castings
EXPLODED VIEW
1105-3406-2-MOD
PIN MODEL 1110-8400
1110-4501
DETENT BALL MODEL 1110-8400-MOD
1109-3206-1-L-ABS (2 pcs.) 8400 shown
dimensioned
HOUSING (3 Light Holes) 1110-4502 LIGHT HOLE PLUG, Weld-on
I.D. 3/4"
used on 1101-3406-L-ABS Twistlock DETENT SPRING Ø19 MM
1109-3206-1-L
HOUSING (2 Light Holes)
used on 1101-3406-L Twistlock
8400 converts
1109-3206-1-R O.D. 2-5/8" 3/8" Ø2-5/16" Light 8400-MOD
eliminates
HOUSING (2 Light Holes) Ø66 MM 9 MM Hole to Ø3/4" Light Hole
used on 1101-3406-R Twistlock
1110-4503 MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER
GREASE FITTING 8400 WEIGHT: 0.3 LBS / 0.136 Kg
8400-MOD WEIGHT: 0.33 LBS / 0.15 Kg
1108-1207-18
LATCH MODEL 1110-8674
1110-4542 I.D. 3/16" LIGHT HOLE PLUG
Ø4.8 MM
HEX NUT 1110-4556-G5 x 3 HOLES
HEX BOLT Bolt-on
1110-4769-G8
HEX BOLT I.D. 3/4"
1110-3706-19R Ø19 MM
LATCH SPRING O.D. 3-1/8" 1/8" Converts Ø2-5/16"
for 1101-3406-L Twistlock
1107-3206-4 Ø79.4 MM 3.5 MM light hole to Ø3/4"
HANDLE 1110-3706-19L
1110-4511 LATCH SPRING MATERIAL: STEEL FINISH: WELDABLE PRIMER
HEX NUT for 1101-3406-R Twistlock WEIGHT: 0.28 LBS / 0.127 Kg
