1401-30
[return to Table of Contents]
SWING DOOR LOCKING SYSTEMS
BLOXWICH-STYLE COMPONENTS
BEARING SPLIT BUSHINGS (Long & Short)
CONTAINERS & VAN TRAILERS

I.D. 1-3/8" MODEL 1401-2613 MODEL 1401-2614
Ø34.8 MM I.D. 1-3/8"
SPLIT BUSHINGS SET Ø35 MM SPLIT BUSHINGS SET
1-1/2"
39.4 MM 2-1/8"
54 MM
1"
26 MM 15/16"
24.6 MM

3" 4-7/16"
76 MM 113 MM 2-3/16" 3-5/8"
56 MM 92 MM
2 PCS., 2 PCS.,
NON-HANDED NON-HANDED

SUB FOR: BLOXWICH 10559 SUB FOR: BLOXWICH 12272
WORKS WITH: 1401-2173, 1401-2541 & 1401-6142 WORKS WITH: 1401-2308 BEARING BRACKET
BEARING BRACKETS MATERIAL: NYLATRON MATERIAL: NYLATRON COLOR: BLACK
COLOR: BLACK WEIGHT: 0.05 LBS / 0.023 Kg WEIGHT: 0.05 LBS / 0.023 Kg

11/16" MODEL 1401-2615-M I.D. 1-3/8" 1-9/16" MODEL 1401-2838
R17.4 MM Ø34.8 MM 38.7 MM
MODEL 1401-2615-F SPLIT BUSHINGS SET
SPLIT BUSHINGS 1"
11/16" 26 MM
17.8 MM 1401

4-3/8" 3"
111.9 MM 76.3 MM 4" 6-13/16"
102 MM 173 MM
2615-M 2615-F
11/16" LONG MALE LONG FEMALE 2 PCS.,
17.8 MM NON-HANDED
SUB FOR: BLOXWICH 10554 (Female), 10555 (Male) SUB FOR: BLOXWICH 10561
WORKS WITH: 1401-2541 BEARING BRACKET & WORKS WITH: 1401-2542 & 1401-7030 LONG
1401-2174 BACK PLATE MATERIAL: NYLATRON BEARING BRACKETS MATERIAL: NYLATRON
COLOR: BLACK WEIGHT: 0.05 LBS / 0.023 Kg COLOR: WHITE WEIGHT: 0.069 LBS / 0.031 Kg

MODEL 1401-6113 MODEL 1401-6156
SPLIT BUSHINGS SET I.D. 1-3/8" SPLIT BUSHINGS SET
I.D. 1-3/8"
Ø34.8 MM Ø34.8 MM
1-1/2"
1-9/16" 38.8 MM
38.8 MM
1" 1-3/16"
26.2 MM 30 MM
2 PCS., 2 PCS.,
1-7/16" NON-HANDED 1-7/16" NON-HANDED
37 MM 37 MM

SUB FOR: BLOXWICH 10560 SUB FOR: BLOXWICH 10562
WORKS WITH: 1401-2175 SHORT BEARING BRACKET WORKS WITH: 1401-2785 SHORT BEARING BRACKET
MATERIAL: NYLATRON COLOR: GRAY MATERIAL: NYLATRON COLOR: GRAY
WEIGHT: 0.02 LBS / 0.01 Kg WEIGHT: 0.02 LBS / 0.01 Kg

904-696-0010
E-mail: sales@buffersusa.com
1401-30 9/3/24
