1105-26
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1512-L
MODEL 1105-1512-R
2"
50.8 MM 1105-1512-L 1105-1512-R for Strick chassis
7/16"
11.1 MM
2-1/8"
O.D. 2-1/4" 54 MM
Ø57.2 MM 3-7/8"
I.D. 3/8" 4-9/16" 98.4 MM
1105 3-1/4" Ø9.5 MM 115.9 MM 45º
82.6 MM 8-5/16" 2-1/4"
211.1 MM 57.2 MM

O.D. 1-3/4" SUB FOR: PENZ 15-43-XX WORKS WITH: BUFFERS 1107-1387 & 1107-1480 HANDLES
Ø44.5 MM MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 7.25 LBS / 3.29 Kg

MODEL 1105-1515-L
2"
50.8 MM 1105-1515-L 1105-1515-R MODEL 1105-1515-R
for Allied chassis

3-7/8"
I.D. 3/4" 2-7/8" 98.4 MM
Ø19.4 MM 73.8 MM
45º
6" 2-1/4"
152.4 MM 57.2 MM

O.D. 1-3/4"
Ø44.5 MM SUB FOR: PENZ 15-49-XX MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 6.5 LBS / 2.95 Kg

MODEL 1105-1516-L
2"
50.8 MM 1105-1516-L 1105-1516-R MODEL 1105-1516-R

3-7/8"
98.4 MM
4-1/2" 45º
I.D. 1/2" 114.3 MM
Ø12.7 MM 2-1/4"
57.2 MM
6-1/2"
165.1 MM

O.D. 1-5/8"
Ø41.3 MM SUB FOR: PENZ 15-84-XX MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 5.2 LBS / 2.36 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-26 12/5/22
