1105-29
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1555-L
MODEL 1105-1555-R
1-1/4"
31.8 MM 1/16" 1105-1555-L 1105-1555-R
1.6 MM
3-3/4"
O.D. 2" 95.3 MM
Ø50.8 MM 45º 45º
4-3/16"
I.D. 7/16" 1-3/16" 106.4 MM 2"
Ø11.1 MM 30.2 MM 50.8 MM
5-5/8"
142.9 MM 1105
I.D. 11/16" I.D. 7/16" I.D. 11/16"
Ø17.5 MM Ø11.1 MM Ø17.5 MM
O.D. 1-1/2"
Ø38.1 MM SUB FOR: PENZ 15-116-XX MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.19 LBS / 1.9 Kg

2"
50.8 MM MODEL 1105-1579

I.D. 1/2" 2-5/8" 3-7/8"
Ø12.7 MM 66.7 MM 4-11/16" 98.4 MM
119.1 MM
8-5/8" 2-1/4"
219.1 MM 57.2 MM

O.D. 1-3/4" SUB FOR: PENZ 15-28-B WORKS WITH: BUFFERS 1107-1376 & 1107-1556 HANDLES
Ø44.5 MM MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 7.3 LBS / 3.31 Kg

MODEL 1105-1616
for Penz 90-35 series Drop-in Twistlocks
1-3/16" w/ 70° handle rotation
30 MM
1/16"
1.5 MM
O.D. 2" I.D. 3/8" 1-5/8" 3-11/16"
Ø50.8 MM Ø10.3 MM 41.3 MM 94 MM
5-1/8" 4-1/16"
130.2 MM I.D. 9/16" 103.2 MM 2-1/4"
Ø15.1 MM 56 MM

O.D. 1-1/2"
Ø38 MM SUB FOR: PENZ 15-131F FITS: PENZ 90-35-XXF & 90-35A-XX TWISTLOCKS
WORKS WITH: BUFFERS 1107-1647-L/R (for 90-35) & 1107-7351-L/R (for 90-35A) HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.59 LBS / 1.63 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-29 12/6/22
