1105-30
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1636
1-3/16" for Penz 90-03 Drop-in Twistlock
30 MM 1/16"
1.6 MM
O.D. 2" 3-11/16"
Ø50.8 MM 94 MM
4-1/2"
I.D. 3/8" 1-13/16" 114.3 MM 2-1/4"
Ø10.3 MM 46 MM 5-7/16" 56 MM
I.D. 9/16" 138.1 MM
1105 Ø15.1 MM
O.D. 1-1/2"
Ø38 MM
SUB FOR: PENZ 15-78 FITS: PENZ 90-03 TWISTLOCK
WORKS WITH: BUFFERS 1107-1561 HANDLE MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 3.87 LBS / 1.76 Kg

MODEL 1105-1637-10
2"
50.8 MM MODEL 1105-1637-12
UNDRILLED w/ High Cone

3-7/8"
98.4 MM

10" / 254 MM 2-1/4"
or 57.2 MM
12" / 305 MM

SEE ALSO: SUB 12" FOR: PENZ 15-79
1105-1454 MATERIAL: FORGED STEEL
FOR 8-1/4" FINISH: PRIMER
PIN HEIGHT 10" WEIGHT: 7.6 LBS / 3.45 Kg
O.D. 1-1/2" 12" WEIGHT: 8.5 LBS / 3.86 Kg
Ø38.1 MM

MODEL 1105-1661
1-1/4"
31.8 MM for Penz 90-12 series Twistlocks
1/16"
1.6 MM
O.D. 2"
Ø50.8 MM I.D. 3/8" 1-13/16"
Ø10.3 MM 46 MM 3-3/4"
95.3 MM
5-7/8"
6-7/8" 149.2 MM 2"
174.6 MM 50.8 MM
I.D. 9/16"
Ø15.1 MM

O.D. 1-1/2" SUB FOR: PENZ 15-98 FITS: PENZ 90-12, 90-12-OT & 90-12-OT/A TWISTLOCKS
Ø38.1 MM
WORKS WITH: BUFFERS 1107-1725 & 1107-1726 HANDLES, 1108-1633 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.7 LBS / 2.13 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-30 12/6/22
