TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1539
1-1/4"
31.8 MM 1/16"
1.6 MM
O.D. 2" I.D. 3/8"
Ø50.8 MM Ø9.5 MM 3-3/4"
95.3 MM
5-9/16" 1-1/16"
141.3 MM 27 MM 2"
6-3/16" 50.8 MM
I.D. 9/16" 157.2 MM
1105 Ø14.3 MM

O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-119 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.48 LBS / 2.03 Kg

NOTE: This Pin is used on the Blair 149/2NR Twistlock w/ MODEL 1105-1540
ROUND Handle. Use model 1105-2445 Pin for FLAT Handle. for Blair 149/2NR Twistlock
(w/ Round Handle)
1-1/4"
31.8 MM

3-3/4"
2-1/2" 95.3 MM
63.5 MM
3/8" 5" 3/8" 2"
9.7 MM 127 MM 9.7 MM 50.8 MM
5-1/2"
I.D. 1/2" 139.7 MM
Ø12.7 MM

O.D. 1-15/32" SUB FOR: BLAIR 1067 (for Round Handle) FITS: BLAIR 149/2NR TWISTLOCK (w/ Round Handle)
Ø37.5 MM WORKS WITH: BUFFERS 1107-1542-A ROUND HANDLE & 1107-1542-B COLLAR
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.95 LBS / 1.79 Kg

MODEL 1105-1543
1-1/4"
31.8 MM 1/16" for Penz 90-32C & 90-32CABS
1.6 MM Twistlocks
O.D. 2"
Ø50.8 MM
I.D. 13/32" 1-9/16" 7-1/4" 3-3/4"
Ø10.3 MM 39.7 MM 184.1 MM 95.3 MM
6-5/16" 2"
160.3 MM 50.8 MM
I.D. 19/32"
Ø15.1 MM

O.D. 1-1/2" SUB FOR: PENZ 15-126 FITS: PENZ 90-32C-XX & 90-32CABS-XX TWISTLOCKS
Ø38.1 MM WORKS WITH: BUFFERS 1107-1728-L/R HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.98 LBS / 2.26 Kg
