1105-25
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-1509
for J.B. Hunt chassis
1-1/4"
31.8 MM
1/16" 1-3/8"
1.6 MM 34.9 MM
O.D. 2" I.D. 7/16"
3-3/4"
Ø50.8 MM Ø11 MM 95.3 MM
3-13/16"
4-13/16" I.D. 9/16" 96.8 MM
2"
122.2 MM Ø15.1 MM 50.8 MM
1105
O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-124 FITS: BUFFERS 1102-3247 & PENZ 90-33-XXF TWISTLOCKS
WORKS WITH: BUFFERS 1107-1618-L/R HANDLES MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 3.67 LBS / 1.67 Kg

MODEL 1105-1510
2" for Budd & Gindy chassis
50.8 MM

3-7/8"
98.4 MM
I.D. 1" 3-3/8" I.D. 5/16" 3-3/8"
Ø26.2 MM 85.7 MM Ø7.9 MM 85.7 MM 2-1/4"
5-1/4" 57 MM
133.4 MM

O.D. 1-15/16"
Ø49.2 MM
SUB FOR: PENZ 15-31 WORKS WITH: BUFFERS 1107-1386 HANDLE (Bent 90°)
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.7 LBS / 3.04 Kg

MODEL 1105-1511
2" for Budd & Gindy chassis
50.8 MM

3-7/8"
4-1/4"
3-3/4" 108 MM 4-1/4" 98.4 MM
I.D. 1" 95 MM 108 MM 2-1/4"
Ø26.2 MM 5-1/4" 57 MM
133.4 MM
I.D. 5/16"
Ø7.9 MM
O.D. 1-15/16"
Ø49.2 MM
SUB FOR: PENZ 15-32 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 6.5 LBS / 2.95 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-25 12/5/22
