1105-10
[return to Table of Contents]
INNER PIN ASSEMBLIES
for SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS

1-1/16" MODEL 1105-1129-INNER
26 MM

7" 3-11/16"
O.D. 1-1/2" 177.5 MM 94 MM
Ø38 MM
7-5/8"
192.5 MM O.D. 5/8"
Ø16 MM
2-1/4"
56 MM
1105
O.D. 1-1/4" 5"
Ø31.5 MM 127 MM
SOLD ONLY AS ASSEMBLY: FITS: BUFFERS 1101-1129 TWISTLOCK, DURALOC 1101-1150 TWISTLOCK &
Shear Block, Detent Balls, Spring, WEST LAKE 60-16 TWISTLOCK w/ BUFFERS 1109-1129-60 CONVERSION BUSHING
Grease Fittings, Hand Nut, Split Roll WORKS WITH: BUFFERS 1107-1133-4 HANDLE
Pin, Handle & Bolts are included. MATERIAL: STEEL FINISH: PRIMER WEIGHT: 6.77 LBS / 3.07 Kg

1-3/16"
30 MM MODEL 1105-1320-INNER
MODEL 1105-1320-INNER-MOD

1320-INNER
8-1/4"
209.5 MM 3-3/4"
O.D. 1320-INNER-MOD 95.3 MM
1-1/2" 8-3/4"
Ø38 MM 222.25 MM
O.D. 5/8"
7-5/8" Ø16 MM
192.5 MM 2-1/4"
57.2 MM
5-1/2" FITS: BUFFERS 1101-1320, 1101-1320-RS-MOD TWISTLOCKS
139.7 MM
WORKS WITH: 1107-1320-4 & 1107-8533-4 HANDLES
SOLD ONLY AS ASSEMBLY: Riser Block, Support MATERIAL: STEEL FINISH: PRIMER
Plate, Detent Balls (4), Springs (2), Grease Fittings (2), 1105-1320-INNER WEIGHT: 10.3 LBS / 4.67 Kg
Split Roll Pin, Handle, Hex Bolt & Hex Lock Nut are included. 1105-1320-INNER-MOD WEIGHT: 9.85 LBS / 4.47 Kg

MODEL 1105-2008-KIT
1-1/16" 1-5/16"
26 MM 33.5 MM PIN for Blair Screwdown Twistlock
1105-2008
3-15/16"
O.D. 2-1/4" 100 MM
5/16" Ø56 MM
7.5 MM 6-5/16"
160 MM 3-11/16"
HAND NUT 94 MM
5-3/4" 1110-2009
145.5 MM HANDLE
1107-2008-4 2-1/4"
13/16" 56 MM
20 MM
O.D. 1-3/16"
Ø30 MM NOTE: HANDLE TO BE WELDED BY CUSTOMER.
KIT CONSISTS OF 1105-2008 PIN, SUB FOR: BLAIR 1713 PIN & BLAIR 1010 HAND NUT FITS: BLAIR TWISTLOCK
1110-2009 HAND NUT & MATERIAL: STEEL FINISH: PRIMER WEIGHT: 6.1 LBS / 2.77 Kg
1107-2008-4 HANDLE.

904-696-0010
E-mail: sales@buffersusa.com
1105-10 10/25/23
