1110-02
[return to Table of Contents]
PINLOCK & TWISTLOCK SPRINGS

CHASSIS | FLATBED TRAILERS

2-1/4" MODEL 1110-1130SA-6 MODEL 1110-1641
2" Ø3/16"

Ø2"
Ø2-7/8"
11/16"
4-1/2"
Ø1/8"
2-1/2"
FITS: BUFFERS 1101-1130-SA TWISTLOCK SUB FOR: PENZ 50-12
MATERIAL: STAINLESS STEEL FITS: BERTOLINI MATERIAL: SPRING STEEL
WEIGHT: 0.14 LBS / 63.5 g WEIGHT: 0.43 LBS / 192.8 g
1110

MODEL 1110-1646 MODEL 1110-1648
Ø1/16" Ø1/16"

Ø11/16" Ø9/16"
2-1/2"
3-9/16" 1-3/16" 2-7/8" 1-1/2"
5-9/16"

SUB FOR: PENZ 50-13 SUB FOR: PENZ 50-25
MATERIAL: SPRING STEEL MATERIAL: SPRING STEEL
WEIGHT: 0.08 LBS / 36.2 g WEIGHT: 0.07 LBS / 31.8 g

MODEL 1110-1775 MODEL 1110-1777
Ø1/16"
2-11/16"
Ø1/8"
Ø7/8" Ø27/32"

7-11/16" 1-7/16"
2-25/32"

SUB FOR: PENZ 50-14 SUB FOR: PENZ 50-15
FITS: THEURER MATERIAL: SPRING STEEL MATERIAL: SPRING STEEL
WEIGHT: 0.17 LBS / 77.1 g WEIGHT: 0.07 LBS / 31.8 g

Ø3/32" MODEL 1110-1794 MODEL 1110-1855
1-7/8"
Ø1/8"
21/32"
Ø7/8"
7-3/4"
21/32" 1-31/32"

FITS: SCHULZ FB44HL PINLOCK LATCH SUB FOR: PENZ 50-16
1-31/32" MATERIAL: SPRING STEEL FITS: THEURER MATERIAL: SPRING STEEL
WEIGHT: 0.02 LBS / 9.07 g WEIGHT: 0.27 LBS / 122.5 g

904-696-0010
E-mail: sales@buffersusa.com
1110-2 12/14/20
