1109-06
[return to Table of Contents]
HOUSINGS & RISER BLOCK

for DROP-IN TWISTLOCKS
CHASSIS

O.D. 3-15/16" MODEL 1109-1257-1
Ø100 MM
MODEL 1109-1257-1-SC
HOUSING
9/16" 1-1/4"
2-1/4" 14 MM 32 MM
57 MM
4-3/4"
94 MM
O.D. 2-1/4" 1-7/8"
Ø57 MM 48 MM
I.D. 1-9/16" O.D. 3-3/16"
Ø40 MM
1109 Ø81 MM
WORKS WITH: BUFFERS 1102-1257-L/R, 1102-1257-LP-L/R, 1102-1259-L/R, 1102-3229-L/R,
1102-3257-L/R, 1102-3258, 1102-3259-L/R, 1102-3260-L/R, 1102-3261-L/R, 1102-3262-L/R,
1102-3267-L/R, 1102-3269-L/R, 1102-3557-L/R , 1102-3559-L/R DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER or SELF-COLOR (-SC) WEIGHT: 3.5 LBS / 1.59 Kg

O.D. 3-15/16" MODEL 1109-1690-1
Ø100 MM
SPECIAL ORDER ONLY MODEL 1109-1690-1-SC
HOUSING
1-5/16"
2-1/4" 5/8" 33.5 MM
57 MM 16 MM
2-5/16"
58.5 MM

O.D. 2-1/4" 3/8"
I.D. 1-9/16" Ø57 MM 9 MM
Ø40 MM O.D. 3-3/16"
Ø81 MM

WORKS WITH: BUFFERS 1102-1690-L/R, 1102-1691 DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER or SELF-COLOR (-SC) WEIGHT: 3.17 LBS / 1.44 Kg

MODEL 1109-1845
O.D. 3-7/8"
Ø98 MM RISER BLOCK

5/8" 1-5/16"
16 MM 33.5 MM
2-1/4" 3"
57 MM 76 MM
1-1/16"
26.5 MM
O.D. 2-1/4"
I.D. 1-9/16" Ø57 MM
Ø40 MM
O.D. 3-3/16"
Ø81 MM

SUB FOR: PENZ 21-32 FITS: BUFFERS 1102-1625-L/R & PENZ 90-41-XXF DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: WELDABLE PRIMER WEIGHT: 3.1 LBS / 1.41 Kg

904-696-0010
E-mail: sales@buffersusa.com
1109-6 10/26/22
