1111-01
[return to Table of Contents]
PIN NUT WRENCHES

for SCREWDOWN TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1111-1244
PIN NUT WRENCH
for Screwdown Twistlocks

3/8"
10 MM

O.D. 4-3/4"
Ø120 MM
1111

1-3/16" I.D. 3-3/4"
30 MM Ø96 MM
5/8"
16 MM
x 8 places
11-13/16"
300 MM

FRONT VIEW
WORKS WITH: 1110-1129-14 PIN NUT (1" tall, used on Buffers 3539 series Screwdown Twistlocks)
MATERIAL: CAST STEEL FINISH: HOT-DIP & SPIN GALVANIZED WEIGHT: 2.19 LBS / 0.99 Kg

MODEL 1111-8122
PIN NUT WRENCH
for Screwdown Twistlocks

3/8"
10 MM

1-3/16" 5/8"
30 MM 16 MM
1-15/16" Shown in use w/
49.5 MM 1110-3629-14 Pin Nut
on 1101-3829-RS Twistlock

1-15/16"
49.5 MM 4-1/8"
11-13/16" 104.7 MM
300 MM
13"
332.2 MM
WORKS WITH: 1110-3629-14 PIN NUT (1-5/8" tall, used on Buffers 3629, 3729 & 3829 series Screwdown Twistlocks)
MATERIAL: CAST STEEL FINISH: HOT-DIP GALVANIZED WEIGHT: 2.11 LBS / 0.96 Kg

904-696-0010
E-mail: sales@buffersusa.com
1111-1 1/4/23
