1110-05
[return to Table of Contents]
TWISTLOCK LIGHT HOLE

CONVERTERS & PLUGS
CHASSIS

MODEL 1110-1206-30
I.D. 9/32"
Ø7 MM LIGHT HOLE PLUG COVER
Can be installed Bolt-on or Rivet
w/ 1/4" Bolts
or Rivets (2 pcs. per hole needed)
1/4"
FRONT VIEW BACK VIEW 6 MM
O.D. 2-5/8" O.D. 2-1/4"
Ø66 MM Ø57 MM

FITS: BUFFERS 1101-1206-L/R TWISTLOCKS MODEL 1206 w/
MATERIAL: CAST STEEL FINISH: PRIMER WEIGHT: 0.3 LBS / 0.13 Kg LIGHT HOLE PLUGS
INSTALLED
1110

MODEL 1110-1209
LIGHT HOLE PLUG
Push-in
O.D. 2-3/4" O.D. 2-7/8"
Ø70 MM Ø73.5 MM

MATERIAL: EPDM RUBBER
NOTE: Must install before twistlock COLOR: BLACK
5/8"
15 MM housing is welded to chassis. WEIGHT: 0.06 LBS / 0.03 Kg

A SECTION A-A MODEL 1110-8400
LIGHT HOLE CONVERTER PLUG
1/8" Weld-on
3 MM 8400 converts
Ø2-5/16" Light MODEL 1110-8400-MOD
I.D. 3/4" O.D. 2-5/16" Hole to Ø3/4"
Ø19 MM Ø58 MM LIGHT HOLE PLUG, Weld-on

8400-MOD MATERIAL: CAST STEEL
I.D. 2" eliminates Ø2-5/16"
O.D. 2-5/8" A Ø52 MM 3/8" Light Hole FINISH: PRIMER
Ø66 MM 9 MM 8400 WEIGHT: 0.3 LBS / 0.136 Kg
8400-MOD WT.: 0.33 LBS / 0.15 Kg
8400 shown dimensioned. 8400-MOD has no center hole.

MODEL 1110-8674
I.D. 3/16"
I.D. 3/4" Ø4.8 MM MODEL 1110-8674-5 *
Ø19 MM x 3 Holes (8674) 8674
x 5 Holes (8674-5)* 3 Bolt Holes, LIGHT HOLE
Converts Ø2-5/16" CONVERTER PLATE
Light Hole to Ø3/4" Bolt-on or Rivet
*1-3/4"
44 MM 2-3/4"
(C-C)
Ø70 MM 8674-5*
(holes center dia.) 5 Bolt Holes, MATERIAL: STEEL
Converts Ø2-5/16" FINISH: PRIMER
O.D. 3-1/8" 1/8" Light Hole to Ø3/4"
Ø79.4 MM 3.5 MM WEIGHT: 0.28 LBS / 0.127 Kg

904-696-0010
