1109-07
[return to Table of Contents]
HOUSINGS

for DROP-IN TWISTLOCKS
CHASSIS

MODEL 1109-3027-1
O.D. 3-15/16"
Ø100 MM HOUSING

3/8"
2-1/4" 8.5 MM 1-5/16" 1-11/16"
57 MM 33.5 MM 42 MM

O.D. 3-3/16"
Ø81 MM
I.D. 1-1/2" 1109
Ø39 MM
WORKS WITH:
BUFFERS 1102-3027-L/R DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER
WEIGHT: 2.64 LBS / 1.2 Kg

MODEL 1109-3247-1
O.D. 3-7/8"
Ø98 MM HOUSING

9/16"
14 MM 1"
25.5 MM
2-1/4"
57 MM 2-3/4"
69.5 MM
1-3/16"
30 MM
O.D. 2-1/4"
I.D. 1-9/16" Ø57 MM
Ø40 MM
O.D. 3-3/16" WORKS WITH:
Ø81 MM BUFFERS 1102-3247-L/R DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER
WEIGHT: 3.08 LBS / 1.4 Kg

MODEL 1109-3248-1
O.D. 3-7/8" HOUSING
Ø98 MM
9/16" 1"
14 MM 25.5 MM
2-1/4"
57 MM 3-3/4"
94 MM
2-3/16"
54.5 MM
O.D. 2-1/4"
Ø57 MM
I.D. 1-9/16" O.D. 3-3/16"
Ø40 MM Ø81 MM

WORKS WITH: BUFFERS 1102-3248-L/R DROP-IN TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER WEIGHT: 3.56 LBS / 1.62 Kg

904-696-0010
E-mail: sales@buffersusa.com
1109-7 10/27/22
