1109-09
[return to Table of Contents]
BUSHINGS, GUIDE BOSSES &
WASHERS for TWISTLOCKS & PINLOCKS
PIN-REDUCING SLEEVE for PINLOCKS
CHASSIS

Ø Inner BUSHINGS, GUIDE BOSSES
Diameter Thickness & WASHERS
B C
A Ø Outer
Diameter MATERIAL: STEEL

MODEL Item Description A B C WEIGHT FINISH SUB FOR
1109-2048 Riser Block Washer 2" / 50.8 MM 3-7/8" / 98.4 MM 1/4" / 6.4 MM 0.61 LBS / 0.28 Kg Primer Penz 21-29
1109-4630 Std. R/NR Twl Bushing 1-9/16" / 39.7 MM 2-3/8" / 60.2 MM 7/32" / 6 MM 0.16 LBS / 0.07 Kg Primer
1109-4630-HDG* Std. R/NR Twl Bushing 1-9/16" / 39.7 MM 2-3/8" / 60.2 MM 7/32" / 6 MM 0.16 LBS / 0.07 Kg HDG* *SPECIAL ORDER
1109-4515 Std. R/NR Twl Bushing 1-9/16" / 39.7 MM 2-3/8" / 60.2 MM 3/16" / 4.8 MM 0.1 LBS / 0.05 Kg Primer
1109-4517 Screwdown Twl Bushing 1-9/16" / 39.7 MM 2-11/32" / 59.5 MM 19/32" / 15.1 MM 0.4 LBS / 0.18 Kg Primer
1109-4528 Twistlock Bushing 1-9/16" / 39.7 MM 2-11/32" / 59.5 MM 3/8" / 9.5 MM 0.27 LBS / 0.12 Kg Primer Penz 40-24 1109
1109-4528-HDG* Twistlock Bushing 1-9/16" / 39.7 MM 2-11/32" / 59.5 MM 3/8" / 9.5 MM 0.27 LBS / 0.12 Kg HDG* *SPECIAL ORDER
1109-4633 Bushing 1-9/16" / 39.7 MM 2-11/32" / 59.5 MM 9/32" / 7 MM 0.13 LBS / 0.06 Kg Primer
1109-4527 Drop-In Twl Bushing 1-9/16" / 39.7 MM 2-11/32" / 59.5 MM 1/8" / 3.2 MM 0.08 LBS / 0.04 Kg Primer
1109-1632 Bushing/Guide Boss 1-9/16" / 39.7 MM 2-1/2" / 63.5 MM 5/8" / 15.9 MM 1 LB / 0.45 Kg Primer Penz 40-10
1109-1763-9 Twistlock Guide Boss 1-9/16" / 39.7 MM 2" / 50.8 MM 11/32" / 9 MM 0.12 LBS / 0.06 Kg Primer
1109-1762 Pinlock Guide Boss 1-9/16" / 39.7 MM 2" / 50.8 MM 1-1/4" / 31.8 MM 0.43 LBS / 0.2 Kg Primer Penz 40-01
1109-1763 Pinlock Guide Boss 1-9/16" / 39.7 MM 2" / 50.8 MM 4" / 101.6 MM 1.39 LBS / 0.63 Kg Primer Penz 40-06

MODEL 1109-7360
Ø7/16" PINLOCK GUIDE BOSS
I.D. w/ dual Ø7/16" side holes
Ø1-3/16"
SUB FOR: PENZ 40-15
MATERIAL: FAB. STEEL
FINISH: PRIMER
1-1/4" O.D. WEIGHT: 0.43 LBS / 0.2 Kg
Ø1-3/4"

MODEL 1109-8705
Tabs (2) spring back into original
position after insertion in the PIN REDUCING SLEEVE
Ø40 mm Pinlock Housing. I.D. Ø40 MM to Ø33.5 MM

USE WITH: PIN 1106-8706
(see catalog pg. 1106-15)
1-11/16"
43 MM
B
3/32"
1/8" 2 MM
3 MM
O.D. 1-11/16" I.D. 1-5/16" O.D. 1-9/16"
Ø42 MM Ø33.5 MM Ø39.5 MM
A

B SECTION B-B

WORKS WITH: 1106-8706 PIN for 1103-1175 & 1103-1213 PINLOCKS
MATERIAL: CHROMOLY STEEL FINISH: WELDABLE PRIMER WEIGHT: 0.22 LBS / 0.1 Kg
A
