Page 271 - Buffers USA 2024 Chassis Hardware Catalog FlipBook
P. 271
1109-05
[return to Table of Contents]
SHEAR BLOCK
for TWISTLOCKS
CHASSIS
O.D. 3-23/32" MODEL 1109-3837-3
Ø94.2 MM
2-3/16"
55.6 MM
I.D. 1-17/32"
Ø38.8 MM
1-5/16"
33.5 MM 1109
WORKS WITH: BUFFERS 1101-3837-R/-NR
& 1101-3843-R/-NR CHASSIS TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER
O.D. 1-27/32" 1/4" WEIGHT: 2.09 LBS / 0.95 Kg
Ø47.2 MM 7 MM
904-696-0010
E-mail: sales@buffersusa.com
1109-5 10/25/22
