1108-16
[return to Table of Contents]
SAFETY LATCHES

for TWISTLOCKS
CHASSIS | FLATBED TRAILERS

MODEL 1108-3633-18

SPECIAL ORDER ONLY MODEL 1108-3633-18-HDG
LATCH for RETRACTABLE TWISTLOCKS
Buffers 3100, 3500, 3600, 3700, 3800 & 3900 series
1108-3633-18
Replaces 4-3/16" FITS: BUFFERS 1101-3133, 1101-3137,
1108-3133-18 1101-3189, 1101-3190, 1101-3423, 1101-3523,
1101-3533, 1101-3590, 1101-3623, 1101-3633,
1101-3637, 1101-3690, 1101-3693, 1101-3733,
1101-3837, 1101-3843 & 1101-3943
TWISTLOCKS MATERIAL: CAST STEEL
FINISH: PRIMER or HOT-DIP
GALVANIZED (-HDG) WEIGHT: 1.38 LBS
1108 4-7/8"
MODEL 1108-3633-18-KIT-HDG

1-3/16" LATCH KIT for 3633-R-HDG Twistlock includes:
1-1/2"
1 ea. 1108-3633-18-HDG Latch, 1110-3533-19 Latch
Spring, 1110-4542-SS Hex Nut & 1110-4641 Hex Bolt
I.D. Ø3/8" I.D. Ø7/16"

MODEL 1108-3634-18
LATCH for NON-RETRACTABLE
TWISTLOCKS
Buffers 3500 &
1108-3634-18 3600 series
Replaces 4-3/16"
1108-3534-18

4-1/2"

1-3/16" FITS: BUFFERS 1101-3524-NR, 1101-3534-NR, 1101-3541-NR,
1101-3593-NR, 1101-3594-NR, 1101-3624-NR & 1101-3634-NR TWISTLOCKS
MATERIAL: CAST STEEL FINISH: PRIMER WEIGHT: 1.34 LBS
I.D. Ø13/32" I.D. Ø5/8"

MODEL 1108-3817-18
I.D. 3/8" LATCH for NON-RETRACTABLE
Ø10 MM TWISTLOCKS
Buffers 3817-L/R
15/16" 7/16" w/ Light Holes
24 MM 11 MM
15/16"
24 MM
4-9/16"
116 MM
7/8"
22 MM
FITS: BUFFERS 1101-3817-L/R NON-RETRACTABLE
I.D. 3/8" 15/16"
Ø10 MM 23 MM TWISTLOCKS w/ LIGHT HOLES MATERIAL: CAST STEEL
FINISH: WELDABLE RED PRIMER WEIGHT: 0.37 LBS

904-696-0010
E-mail: sales@buffersusa.com
1108-16 5/4/23
