SAFETY LATCHES
for PINLOCKS & TWISTLOCKS
CHASSIS | FLATBED TRAILERS
MODEL 1108-6307-L
1-1/4" 2-1/8" MODEL 1108-6307-R
9/16" LATCH for 1642-L/R PINLOCKS
1" Special repair to 1642-18 Latch
I.D. Ø7/16" 1-13/16" due to broken stanchion
x 3 HOLES
1" 2-9/16"
3/8"
3/16"
1108
FITS: BUFFERS 1103-1642 PINLOCK
(when replacing broken stanchion on 1108-1642-18 Latch) MODEL MODEL
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED 1108-6307-L 1108-6307-R
WEIGHT (ea.): 0.24 LB
MODEL 1108-6368-KIT
1110-4513-SS
Cotter Pin LATCH ASSEMBLY
3-1/8"
1110-4512 4-1/8"
Washer
1108-6368 1110-4666
Latch Latch Pin O.D.
Ø3/8"
1108-6368-KIT is ONLY sold assembled.
Latch & Pin are NOT sold separately; Cotter Pin & Washer ARE sold separately.
SUB FOR: HOLLAND REPAIR KIT GL-726-099-199 FITS: HOLLAND NON-RETRACTABLE GL-726-099-195-F
& RETRACTABLE GL-726-099-196 TWISTLOCKS 6368 MATERIAL: CAST STEEL 6368 FINISH: PRIMER
4666 MATERIAL: FORGED STEEL 4666 FINISH: ZINC-PLATED 4512 MATERIAL: STEEL 4512 FINISH: ZINC-PLATED
4513-SS MATERIAL: STAINLESS STEEL 4513-SS FINISH: MILLED 6368-KIT WEIGHT: 2.54 LBS
I.D. Ø3/8" MODEL 1108-7354
x 2 HOLES
3-1/8" 1/2"
3-1/8"
1/2"
1-1/2"
1/4"
2-1/8" 1"
3-3/4"
SUB FOR: PENZ 25-17
MATERIAL: FAB. STEEL FINISH: ZINC-PLATED
WEIGHT: 0.39 LBS
