P. 263
1108-15
[return to Table of Contents]
SAFETY LATCH
for 3600-HA-KIT HEIGHT-ADJUSTABLE &
RETRACTABLE TWISTLOCK (older design)
FLATBED TRAILERS
TOP
VIEW *IMPORTANT NOTICE MODEL 1108-3600-HA-18-SL
Please note that a latch such as 1108-3600-HA-18-SL SWING LATCH ASSEMBLY* for
is required to prevent accidental opening of the 1101-3600-HA-KIT Height-Adjustable Twistlock
1101-3600-HA-KIT model lock (older style w/ 112mm (ONLY fits model WITHOUT extension tube)
Pin Sleeve). Due to the various trailer designs and limited
space around this type of lock, Buffers can only offer latch
assemblies that the lock installer needs to weld in place
on the housing that fits each individual application.
See Catalog page 1101-40 for the 1101-3600-HA-KIT
4-7/8" Twistlock Assembly (older/discontinued design).
124 MM
3-1/4" 3-1/4"
83 MM 83 MM 1
5 6
1108
4
3
2
6-1/8"
156 MM
FRONT SIDE
VIEW VIEW
EST. WEIGHT:
1.73 LBS / 0.79 Kg
ITEM # QTY. PART # DESCRIPTION MATERIAL / FINISH
1 1 1101-3600-HA-18-SL-A HINGE BRACKET CAST STEEL / WELDABLE PRIMER
2 1 1101-3600-HA-18-SL-B LATCH LEG CAST STEEL / HDG
3 1 1110-4792-SS PULL PIN STAINLESS STEEL / SELF-COLOR
4 1 1110-4511 HEX NUT STD. CARBON STEEL w/ Nylon Insert / ZINC-PLATED
5 1 1110-4791-SS HEX BOLT STAINLESS STEEL / SELF-COLOR
6 1 1110-4542-SS HEX NUT STAINLESS STEEL w/ Nylon Insert / SELF-COLOR
SWING LATCH ASSEMBLY shown mounted on the 1101-3600-HA-KIT Twistlock WITHOUT extension tube* (sold separately):
7-13/16"
198 MM
6"
152 MM
C L
3" 3" 7/8"
76 MM 76 MM A 22 MM
B
Pull Pin
locks Latch Leg in 90° 5-1/4"
“DOWN”/locked position 134 MM
Latch shown in
locked position.
DETAIL A Bottom Edge of DETAIL B
3600 Twistlock Housing
Hinge
Bracket 7/8"
22 MM
Hinge Bracket must be
Grind bottom weld mounted flush w/ bottom Pull Pin also locks Latch Leg
flush w/ Twl Housing of Twistlock Housing in“UP”/unlocked position
for Handle operation
904-696-0010
E-mail: sales@buffersusa.com
1108-15 5/4/23
