1105-46
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-2996
for Utility chassis
1-1/4"
31.8 MM 1/16"
1.6 MM
O.D. 2"
Ø50.8 MM 3-3/4"
95.3 MM
4-1/2"
114.3 MM 5-1/4" 2"
I.D. 3/4" 133.4 MM 50.8 MM
Ø19.1 MM
1105

O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PENZ 15-53 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 5.4 LBS / 2.45 Kg

MODEL 1105-3027-2
for Buffers 3027 Drop-in Twistlock
w/ 70° handle rotation
1-3/16"
30 MM I.D. 7/16" 1-1/4" O.D. 3-13/16"
Ø11 MM 31 MM Ø96 MM
I.D. 1/2"
I.D. 7/32" 2-1/2" Ø13 MM 1-15/16" 2-1/4"
Ø5.5 MM 63 MM 49.5 MM 56 MM

O.D. 1-1/2"
Ø38 MM
FITS: BUFFERS 1102-3027 DROP-IN TWISTLOCK
WORKS WITH: BUFFERS 1107-3027-4 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 2.65 LBS / 1.2 Kg

MODEL 1105-3133-2
1-3/16"
30 MM for Buffers 3133, 3190
& 3423 Twistlocks

I.D. 7/16" I.D. 5/16" 1-15/16" 3-11/16"
Ø8 MM
Ø11 MM 50 MM
11/16" 94 MM
18 MM 5-7/16"
138 MM 2-1/4"
6-1/16" I.D. 1/2" 56 MM
153 MM Ø13 MM

O.D. 1-1/2" SUB FOR: PENZ 15-164F
Ø38 MM FITS: BUFFERS 1101-3133-R/NR, 1101-3190-R/NR & 1101-3423-R/NR TWISTLOCKS
WORKS WITH: BUFFERS 1107-3133-4 & 1107-8533-4 STRAIGHT HANDLES
COMPARE AGAINST or 1107-3423-4 & 1107-8723-4 BENT HANDLES, 1108-3133-18 LATCH
PIN 1105-3533-2 MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.3 LBS / 1.95 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-46 12/6/22
