1105-44
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-2889
2"
50.8 MM for Budd & Gindy chassis,
2" stem

3-7/8"
4-1/4" 98.4 MM
108 MM
I.D. 1" 2-1/4"
Ø26.2 MM 7-3/8" 57 MM
187.3 MM
1105

O.D. 2"
Ø50.8 MM SUB FOR: PENZ 15-35 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 8.7 LBS / 3.95 Kg

1-3/16"
30 MM MODEL 1105-2919-10
1/16"
1.5 MM UNDRILLED, 1-1/2" x 10"
O.D. 2-3/16" Also available in 7" & 8" pin heights:
Ø55.5 MM MODEL 1105-2919-7
MODEL 1105-2919-8

10"
254 MM 3-11/16"
94 MM
2-1/4"
56 MM

O.D. 1-1/2" MATERIAL: FORGED STEEL FINISH: PRIMER 10" WEIGHT: 6.52 LBS / 2.96 Kg
Ø38 MM 8" WEIGHT: 5.51 LBS / 2.5 Kg 7" WEIGHT: 4.98 LBS / 2.26 Kg

2" SPECIAL ORDER ONLY MODEL 1105-2921
50.8 MM
UNDRILLED, High Cone,
1-15/16" stem

3-7/8"
98.4 MM
2-1/4"
57 MM
10-1/4"
260.4 MM

SUB FOR: PENZ 15-127
MATERIAL: FORGED STEEL
FINISH: PRIMER
O.D. 1-15/16" WEIGHT: 10.83 LBS / 4.91 Kg
Ø49.2 MM

904-696-0010
E-mail: sales@buffersusa.com
1105-44 12/6/22
