1105-48
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

2"
50.8 MM MODEL 1105-3206-2
for Buffers 3206 & 3207
series Twistlocks

I.D. 7/16" 1-5/16" 3-7/8"
Ø11 MM 33 MM 98.4 MM
7-1/2" 6-13/16"
190 MM 173.5 MM 2-1/4"
I.D. 1/2" 57.2 MM
Ø13 MM
1105

O.D. 1-1/2" FITS: BUFFERS 1101-3206-L/R & 1101-3207-L/R TWISTLOCKS
Ø38.1 MM WORKS WITH: BUFFERS 1107-3206-4 HANDLE & 1108-3206-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.18 LBS / 2.8 Kg

MODEL 1105-3259-2
7/8" for Buffers 1257-LP, 3259 & 3260 Drop-in
22.3 MM 1/16"
1.5 MM 1" Twistlocks w/ 90° handle rotation
26 MM
O.D. 2-1/8"
Ø54 MM
I.D. 7/16" 2-13/16" 3-11/16"
4-7/16" Ø12 MM 71 MM 94 MM
5-1/16"
112 MM 129 MM
I.D. 1/2" 2-1/4"
Ø13 MM 56 MM
O.D. 1-1/2"
Ø38 MM
FITS: BUFFERS 1102-1257-LP-L/R, 1102-3259-L/R & 1102-3260-L/R DROP-IN TWISTLOCKS
WORKS WITH: BUFFERS 1107-1257-4, 1107-1259-4, 1107-3260-4 HANDLES & 1108-1224-2L/R LATCHES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.65 LBS / 1.66 Kg

3/4" MODEL 1105-3406-2-MOD
19 MM
LOW-PROFILE / CUT TYPE
for Crowley chassis

I.D. 7/16"
Ø11 MM 1-5/16" 3-7/8"
33 MM 6-7/8" 98.4 MM
7-5/8" 173.5 MM
194 MM 2-1/4"
57 MM
I.D. 1/2"
Ø13 MM

O.D. 1-1/2" FITS: BUFFERS 1101-3406-L/R & 1101-3407-L/R TWISTLOCKS
Ø38.1 MM
WORKS WITH: BUFFERS 1107-3206-4 HANDLE & 1108-1207-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 5.25 LBS / 2.38 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-48 12/6/22
