P. 184
1105-51
[return to Table of Contents]
TWISTLOCK PINS
CHASSIS | FLATBED TRAILERS
MODEL 1105-3600-29-91 MODEL 1105-3600-29-112
PIN SLEEVE for 1101-3600-HA-9-KIT PIN SLEEVE for 1101-3600-HA-KIT
& 1101-3600-HA-9-NH-KIT (older style) (older style) Twistlock, 112mm height
Twistlocks, 91mm height
5/32" 5/32"
7.5 MM 7.5 MM
1/2" O.D. 2-7/8" I.D. 1-11/16" 1/2"
13 MM Ø72 MM Ø44 MM 13 MM
3-5/8"
91 MM 4-7/16"
112 MM
1105 O.D. 2-1/4"
Ø57 MM Overhead View O.D. 2-1/4"
Ø57 MM
FITS: 1101-3600-HA SERIES TWISTLOCKS (older style w/ round extension tube)
WORKS WITH: 1105-3600-2 PIN & 1105-3600-INNER PIN ASSEMBLY MATERIAL: FORGED STEEL FINISH: PRIMER
1105-3600-29-91 WEIGHT: 1.6 LBS / 0.73 Kg 1105-3600-29-112 WEIGHT: 2.02 LBS / 0.92 Kg
1-3/16" MODEL 1105-3629-2
30 MM
1-11/16"
43 MM MODEL 1105-3629-2-HDG
I.D. 7/16" for Buffers 3629 & 3729 series
Ø11 MM I.D. 5/32" Screwdown Twistlocks
11/16" 3-11/16"
O.D. 1-1/2" 18 MM Ø8 MM 97.5 MM
Ø38 MM 6-15/16"
176 MM O.D. 3-11/16"
Ø94 MM
3-1/8" 8-1/8" 7-5/8"
79 MM 206 MM 1/2" 193.5 MM
12.5 MM 2-1/4"
11/16" 56 MM
17.5 MM I.D. 1/2"
Ø13 MM
1-1/4" 1-3/16"
31.5 MM 30 MM
FITS: BUFFERS 1101-3629 & 1101-3729 SERIES TWISTLOCKS WORKS WITH: 1110-3629-14 PIN NUT & 1107-3529-4 HANDLE
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.65 LBS / 2.11 Kg HDG WEIGHT: 4.85 LBS / 2.2 Kg
MODEL 1105-3817-2
1-3/16"
30 MM 13/16" SPECIAL ORDER ONLY MODEL 1105-3817-2-HDG
20 MM
for Buffers 3817 Twistlocks
3/8" 3/8"
10 MM 10 MM
1/4" 1/4" 3-11/16"
6 MM 6 MM 6-13/16" 94 MM
7-11/16" 172.5 MM
195 MM
2-1/4"
I.D. 1/2" 56 MM
Ø13 MM
O.D. 1-1/2" FITS: BUFFERS 1101-3817-L/R TWISTLOCKS WORKS WITH: 1107-3206-4 BENT HANDLE
Ø38 MM & 1108-3817-18 LATCH MATERIAL: FORGED STEEL FINISH: PRIMER or HDG
3817-2 WEIGHT: 4.95 LBS / 2.25 Kg 3817-2-HDG WEIGHT: 5.05 LBS / 2.29 Kg
904-696-0010
E-mail: sales@buffersusa.com
1105-51 12/6/22
