1105-45
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-2926
2"
50.8 MM for Continental chassis, 1" stem

3-7/8"
98.4 MM
5-5/8"
142.9 MM
6" 2-1/4"
152.4 MM 57 MM
I.D. 3/8"
1105 Ø9.5 MM

O.D. 1"
Ø25.4 MM
SUB FOR: PENZ 15-25-A MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4 LBS / 1.81 Kg

MODEL 1105-2959-2
for Buffers 1101-2959 Flatbed
Height Extender Twistlock
1-3/8"
34 MM
4-1/4"
108 MM
I.D. 7/16" 3-7/16"
Ø11 MM 7/8" 4" I.D. 1/2" 87 MM 2-7/16"
23 MM 102 MM Ø13 MM 61 MM

O.D. 1-11/16"
Ø42 MM
FITS: BUFFERS 1101-2959 FLATBED HEIGHT EXTENDER TWISTLOCK
WORKS WITH: BUFFERS 1107-2959-4 HANDLE & 1108-2959-18 LATCH TAB
MATERIAL: FORGED STEEL FINISH: HOT-DIP GALVANIZED WEIGHT: 5.01 LBS / 2.27 Kg

MODEL 1105-2995
2"
50.8 MM

3-7/8"
98.4 MM
3-11/16"
I.D. 3/8" 2-1/4"
5-1/2" Ø9.5 MM 93.7 MM
139.7 MM 57 MM

O.D. 1-7/16
Ø35.7 MM
SUB FOR: PENZ 15-152 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 5 LBS / 2.27 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-45 12/6/22
