1103-07
[return to Table of Contents]
PINLOCKS

CHASSIS

MODEL 1103-1617-L MODEL 1103-1617-L
SHOWN DIMENSIONED.
MODEL 1103-1617-R IS MODEL 1103-1617-R
THE MIRROR OPPOSITE.
FABRICATED
O.D. 5/8"
Ø16 MM

MODEL 1103-1617-L
for Front Roadside
1103

Same as 1103-1417
but w/ flat-sided Pin

MODEL 1103-1617-R
1" for Front Curbside
25.4 MM
Max. 4-1/16"
103 MM
3-1/4" 2-7/8" 5-3/4"
82.55 MM 73 MM 146 MM
O.D. 5/8"
2-1/2" Ø16 MM O.D. 1-1/2"
63.5 MM Ø38.1 MM

5-1/2"
139.7 MM

EXPLODED VIEWS
1107-1417-4
HANDLE 1110-4525-G5
1110-1417-1-A HEX BOLT FINISH: PRIMER
HANDLE WEIGHT: 4.95 LBS / 2.25 Kg
GUIDE
PLATE
1108-1417-18
LATCH
MODEL 1103-1617-L
for Front Roadside
1109-1417-1-L
HOUSING
1110-4530
LOCK NUT .
1106-1617-2
1110-4503 PIN Fully fabricated design
GREASE FITTING . Compact Design that fits in narrow
. Bolsters
1107-1417-4 Grease Fitting in Housing
1110-4525-G5 HANDLE
HEX BOLT 1110-1417-1-A
HANDLE
GUIDE
PLATE
1108-1417-18
LATCH
MODEL 1103-1617-R
for Front Curbside
1109-1417-1-R
HOUSING
1110-4530
LOCK NUT
1106-1617-2
PIN 1110-4503
GREASE FITTING

904-696-0010
E-mail: sales@buffersusa.com
1103-7 12/9/20
