DISCONTINUED DROP-IN TWISTLOCKS
90° HANDLE ROTATION
CHASSIS
MODEL 1102-3532-MOD-3/8-LP-R
MODEL 1102-3532-MOD-3/8-LP-L
1102 90º
3-1/2" 7-1/2"
89 MM 190.8 MM
MODEL
1102-3532-MOD-3/8-LP-R MODEL
for Front Roadside & Rear Curbside 1102-3532-MOD-3/8-LP-L
3-15/16"
100 MM for Front Curbside & Rear Roadside
B
60° 15/16"
23 MM O.D. 2-3/8" Works with
1-1/4" Ø59.5 MM 3/8"-thick bolster
32 MM
2-1/16" 3-3/16" 3-1/4" 4-3/4"
52.8 MM 80 MM 82.5 MM 120.5 MM
B
EXPLODED VIEW 3/8"
9.5 MM
1105-3532-2-MOD-LP*
1110-4502 PIN
DETENT SPRING
*NOTE: USE 1105-3259-2 PIN
1110-4501 for Aftermarket Pin replacement.
DETENT BALL
(2 pcs.)
SECTION B-B
FINISH: PRIMER
1109-3532-3-MOD-3/8 WEIGHT: 11.77 LBS / 5.34 Kg
SHEARBLOCK
1110-4503 . Low-profile Pin Head works with low-clearance
GREASE FITTING corner fittings on ALL 53' containers in the
U.S. & Canadian markets
1109-3532-1-MOD-3/8 . Designed for use on 53' chassis with a
HOUSING 3/8"-thick bolster
. Standard locking clearance
1110-4511-J
HEX JAM NUT
1110-4510-G8 PLEASE NOTE: Not all Twistlocks are supplied with an
HEX BOLT
1107-1259-4 integral handle latch. All Twistlocks should be outfitted
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.
