TWISTLOCKS – DROP-IN TYPE
90° HANDLE ROTATION
CHASSIS

MODEL 1102-3559-R
MODEL 1102-3559-L

3-3/16"
81 MM
90º
1102
3-9/16" 7-1/2"
90.5 MM 190.5 MM
MODEL 1102-3559-R
for Front Roadside
& Rear Curbside
2"
50.8 MM MODEL 1102-3559-L
for Front Curbside
& Rear Roadside

1-5/16"
33.5 MM

3-3/16" O.D. 3-3/16" 9/16"
3-13/16" 80 MM Ø81 MM
97 MM 14 MM
O.D. 3/4"
Ø19 MM

FINISH: PRIMER
EXPLODED VIEW WEIGHT: 10.64 LBS / 4.8 Kg

1110-4549 1105-3557-2
DETENT BALL PIN
(2 pcs.) . Standard locking clearance
1110-4550 . Dual Grease Fittings
DETENT SPRING
. Weld chamfer on Housing
. Designed to hang straight for welding
. High Cone design
1109-1257-1
1110-4503 HOUSING
GREASE FITTING
(2 pcs.)

1110-4511
LOCK NUT
1110-4524-G5
HEX BOLT
PLEASE NOTE: Not all Twistlocks are supplied with an
integral handle latch. All Twistlocks should be outfitted
1107-1259-4
HANDLE with a handle latch upon installation. See section 1108
for latches that may work for your application.

904-696-0010
E-mail: sales@buffersusa.com
1102-18 3/23/23
