1501-01
[return to Table of Contents]
SLIDER PINS

CHASSIS & TRAILERS: AUTO / DRY VAN / FLATBED

MODEL 1501-2448
Ø9/16"

3/4"

Ø5/8" Ø2"
FITS: CHASSIS KING
MATERIAL: ALLOY STEEL
2-5/16" 3/4" FINISH: ANTI-GALL/LIGHTLY OILED
13-7/8" WEIGHT: 11.2 LBS / 5.08 Kg

MODEL 1501-2632
MODEL 1501-2632-KIT

1/2"
Ø3/8"

Ø1" Ø1-3/8" 1501

2-3/4"
10-1/8" SLIDER PIN
MODEL 1501-2632

1-1/2" SUB FOR: PENZ 35-01 FITS: STRICK
MATERIAL: ALLOY STEEL FINISH: PRIMER
WEIGHT: 2.6 LBS / 1.18 Kg
Ø3/8"
CLEVIS PIN
MODEL 1501-4611
SUB FOR: PENZ 17-16 COTTER PIN
MATERIAL: STD CARBON STEEL FINISH: ZINC-PLATED 1/8" x 3/4"
WEIGHT: 0.054 LBS / 0.025 Kg MODEL 1501-4591-SS

Ø3/16" SUB FOR: PENZ 17-17
MATERIAL: STAINLESS STEEL FINISH: SELF-COLOR
WEIGHT: 0.05 LBS / 0.03 Kg
Ø1-1/2"

6-9/16"
SPRING TO ORDER THE COMPLETE ASSEMBLY,
MODEL 1501-4612 USE MODEL 1501-2632-KIT, WHICH INCLUDES
1501-2632 SLIDER PIN, 1501-4611 CLEVIS PIN,
1501-4612 SPRING & 1501-4591-SS COTTER PIN.
SUB FOR: PENZ 50-23 FITS: STRICK
MATERIAL: STD CARBON STEEL FINISH: PRIMER SUB 1501-2632-KIT FOR: PENZ 35-01-KIT
WEIGHT: 0.051 LBS / 0.023 Kg KIT WEIGHT: 3.17 LBS / 1.44 Kg

904-696-0010
E-mail: sales@buffersusa.com
1501-1 9/23/19
