Page 371 - Buffers USA 2024 Trailer Hardware Catalog FlipBook

1501-05
[return to Table of Contents]
SLIDER PINS

CHASSIS & TRAILERS: AUTO / DRY VAN / FLATBED

MODEL 1501-8076
SLIDER PIN
Manac style

O.D. 1-7/8" 3/16"
Ø47.63 MM 3/16" 4.76 MM @ 45°
4.76 MM @ 45° I.D. 3/8"
Ø9.53 MM
O.D. 1-5/8" O.D. 1-3/16"
Ø41.28 MM Ø30.16 MM
5/16" 7/8"
1-3/8" 2" 7.94 MM 22.23 MM
34.93 MM 50.8 MM 9.5"
241.3 MM
11-13/16" MATERIAL: STEEL
300.04 MM FINISH: WELDABLE PRIMER
WEIGHT: 4.24 LBS / 1.92 Kg
1501

904-696-0010
E-mail: sales@buffersusa.com
1501-5 12/7/23
