1501-06
[return to Table of Contents]
SLIDER PIN PARTS

CHASSIS & TRAILERS: AUTO / DRY VAN / FLATBED

MODEL 1501-6102
2-1/4" PIVOT ARM
Ø3/8" 3/8"
1-5/8"

3/8"
1-3/4"
Ø3/8"
2-1/2"

SUB FOR: PENZ 35-08
1-3/8" MATERIAL: FAB. STEEL
FINISH: PRIMER
12-3/8" WEIGHT: 3.51 LBS / 1.59 Kg

MODEL 1501-6127-1
HANDLE

Ø3/4"
5"
3/8"
1501

7-3/4" Ø1/2" 5/8" 1" 3/8" 3/4"

2" SUB FOR: PENZ 35-10
FITS: 1501-6127-2 HANDLE BRACKET
MATERIAL: FAB. STEEL
7/8" 10-7/8" FINISH: PRIMER
27-5/8" WEIGHT: 6.25 LBS / 2.83 Kg

MODEL 1501-6127-2
HANDLE BRACKET

Ø3/8" x 5 HOLES

2"
1" 6" 6" 1" 1/8"
17"

FITS: 1501-6127-1 HANDLE, PENZ 35-10
MATERIAL: FAB. STEEL
FINISH: PRIMER
WEIGHT: 1.1 LBS / 0.5 Kg

904-696-0010
E-mail: sales@buffersusa.com
1501-6 9/24/19
