1404-04
[return to Table of Contents]
TRAILER DOOR SEALS
for PLYMETAL DOORS
DRY & REEFER VAN TRAILERS

MODEL 1404-6657-168
Models available to fit 1/2" – 1-1/2" Plymetal Doors MODEL 1404-6998-168
MODEL 1404-6999-168
FITS DOOR GASKET MODEL 1404-7000-168
MODEL THICKNESS LENGTH GASKET WEIGHT
1404-6657-168 1/2" (12.7 MM) 168" / 14' 3.1 LBS / 1.41 Kg MODEL 1404-7001-168
1404-6998-168 3/4" (19 MM) 168" / 14' 3.25 LBS / 1.47 Kg DOOR GASKETS
1404-6999-168 1" (25.4 MM) 168" / 14' 3.4 LBS / 1.54 Kg
1404-7000-168 1-1/4" (31.75 MM) 168" / 14' 4.9 LBS / 2.22 Kg
1404-7001-168 1-1/2" (38.1 MM) 168" / 14' 6.15 LBS / 2.79 Kg

Three ridges
for extra sealing

MATERIAL: PVC, DUAL DUROMETER
FINISH: GRAY DUAL DUROMETER DESIGN
w/ IMPROVED SEALING

Soft PVC at ends
for extra sealing

1404
CORNER MODEL 1404-7005
MODEL TABS FIT SIZE
1404-7005 OUTSIDE 3/4" x 3" / 19 MM x 76.6 MM MODEL 1404-7006
1404-7006 INSIDE 3/4" x 2-9/16" / 19 MM x 65 MM MODEL 1404-7007
1404-7007 OUTSIDE (Wide) 1-1/4" x 3-3/16" / 32 MM x 81 MM CORNER TABS
MODELS 7005 & 7006 MODEL 7007
27/32" 1-3/16"
21.5 MM 30 MM
90°
9/16"
7005 90° 14.5 MM
0.039" 3-1/64"
R1 MM 76.5 MM
7005 0.039"
2-9/16" 7006
A A 65 MM 2-33/64" R1 MM
64 MM 3-3/16"
7006
2-5/32" A A 81 MM
55 MM
2-5/8"
90° 66.5 MM
0.079"
Ø2 MM 9/16"
90° 14.5 MM
SECTION A-A
13/16" 0.074"
1-7/32" R20.8 MM 1.9 MM 0.079"
R30.8 MM Ø2 MM
1/8"
0.028" 0.012" 3 MM 5/64"
Ø0.7 MM 5/64" / 1.8 MM Ø0.3 MM 0.043" 1-7/16" SECTION A-A 1.8 MM
x 2 SIDES x 9 SPACES x 10 BUMPS 1-5/32" R36.6 MM
27/32" 1.1 MM
21.5 MM R29.5 MM 3/16"
4.6 MM
1/32" 0.012"
Ø0.8 MM 5/64" / 1.8 MM Ø0.3 MM x 16 BUMPS 7/64"
MATERIAL: PVC, DUAL DUROMETER FINISH: GRAY x 2 SIDES x 15 SPACES 2.8 MM
1-3/16"
30 MM
904-696-0010
E-mail: sales@buffersusa.com
1404-4 7/24/23
