1402-34
[return to Table of Contents]
SWING DOOR HARDWARE
HOLDBACKS
CONTAINERS: DOMCON, ISO & REEFER
TRAILERS: DRY & REEFER VAN

MODEL 1402-8645
DOOR HOLDBACK ASSEMBLY
MODEL 1402-8645-2
LAP LINK
I.D. 1-3/4" 1"
Ø3/8" LAP
LINK
O.D.
Ø3/16" 1"

9-15/16"
9-1/4"
8-5/16"

4"
3/4"

8645 ASSEMBLY SUB FOR: HYUNDAI 10001435
MATERIAL: FAB. STEEL LAP LINK FINISH: ZINC-PLATED
BRACKET & CHAIN FINISH: HOT-DIP GALVANIZED
1402 8645 ASSEMBLY WEIGHT: 0.45 LBS / 0.2 Kg
8645-2 LAP LINK WEIGHT: 0.04 LBS / 0.02 Kg

904-696-0010
E-mail: sales@buffersusa.com
1402-34 5/30/24
