1402-31
[return to Table of Contents]
SWING DOOR HARDWARE
HOLDBACKS
CONTAINERS: DOMCON, ISO & REEFER
TRAILERS: DRY & REEFER VAN

MODEL 1402-2916-4-KIT MODEL 1402-2933-5
MODEL 1402-2916-6-KIT 9" HOLDBACK CHAIN
w/ 4" loop & 5 links
DOOR HOLDBACK
3/8"
1-3/4"
1" Ø3/16" x 4 HOLES

3"
2-5/16 "

9"
4" or 6" BOTH PARTS HAVE SAME PLATE
SIZE & HOLE PATTERN DIMENSIONS

4"
1402-2916-A-4 3/4"
1402-2916-A-6 1402-2916-B
TEE HOLDER BASE PLATE
PLATE

SUB FOR: PENZ P-2007 MATERIAL: FAB. STEEL SUB FOR: PENZ P-2011 MATERIAL: CARBON STEEL CHAIN 1402
FINISH: ZINC-PLATED WEIGHT: 0.4 LBS / 0.18 Kg FINISH: HOT-DIP GALVANIZED WEIGHT: 0.29 LBS / 0.13 Kg

MODEL 1402-6856 SPECIAL ORDER ONLY MODEL 1402-7218
DOOR HOLDBACK DOOR HOLDBACK CABLE
CHAIN ASSEMBLY w/ BRACKET
w/ 3" loop

1" 1/2"
I.D. 3/4" NOTE: This end must capture
Ø3/8" Ø19.1 MM Bracket (part #7566)
1-1/2"
38.1 MM

8-13/16" 7"
8-1/16"
177.8 MM
9-3/8"
I.D. 13/32" BRACKET
Ø10.3 MM PART #7566
1/2"
12.2 MM I.D. 2-1/8"
2-15/16" Ø54 MM
I.D. 3/4"
Ø20 MM
1-3/4"
44.5 MM
Ø5/8"
BRACKET MATERIAL: STEEL FINISH: ZINC-PLATED
SWAGE MATERIAL: ALUMINUM FINISH: SELF-COLOR
SUB FOR: PENZ 25-P2012 MATERIAL: FAB. STEEL CABLE MATERIAL: GALV. STEEL FINISH: CLEAR PVC-COATED
FINISH: HOT-DIP GALVANIZED WEIGHT: 0.22 LBS / 0.1 Kg ASSEMBLY WEIGHT: 0.21 LBS / 0.09 Kg

904-696-0010
E-mail: sales@buffersusa.com
1402-31 5/30/24
