P. 358
1402-30
[return to Table of Contents]
SWING DOOR HARDWARE
HINGE PINS
DRY & REEFER VAN TRAILERS
MODEL 1402-6230 MODEL 1402-7248-KIT-P MODEL 1402-7541
MODEL 1402-6230-SS Includes Hex Bolt, 4 Flat Washers & Hex Nut I.D. 1/8" O.D. 1/2"
Washer Ø3.4 MM Ø12.7 MM
29/64"
I.D. 9/64" O.D. 1/2" O.D. 1-1/16" 3/32" 11.4 MM
Ø27 MM
2.4 MM
Ø3.56 MM Ø12.7 MM Hex Nut
3/4" 3-11/16"
19.1 MM 93.6 MM
4-15/16" / 125 MM 5-1/2" 4"
5-3/8" / 136.5 MM 139.7 MM 101.6 MM
Hex Bolt
SUB FOR: FRUEHAUF 007812-001, SUB FOR: DORSEY 5248614,
MINER HP-1054-12, FLEET ENG. 997-98017 SUB FOR: FLEET ENGINEERS 021-00376 FLEET ENGINEERS 997-98022
MATERIAL: CARBON or STAINLESS STEEL MATERIAL: CARBON STEEL MATERIAL: CARBON STEEL
FINISH: ZINC-PLATED (SS: SELF-COLOR) FINISH: ZINC-PLATED FINISH: ZINC-PLATED
WEIGHT: 0.3 LBS / 0.14 Kg WEIGHT: 0.42 LBS / 0.191 Kg WEIGHT: 0.24 LBS / 0.11 Kg
MODEL 1402-7542 MODEL 1402-7543 MODEL 1402-7544
B 3/64" / 1 MM
I.D. 3/16" O.D. 3/8" O.D. 7/8" O.D. 1/2" SECTION Typ. Knurling
Ø4.8 MM Ø9.5 MM Ø21.8 MM Ø12.7 MM A-A DETAIL B
7/16" I.D. 1/8" 7/32" / 5.8 MM I.D. 1/8" O.D. 5/8"
11.4 MM Ø3.4 MM 5/16" / 8 MM Ø3.4 MM Ø15.8 MM
4-11/16" Knurled Area
(see detail above)
119.8 MM O.D. 3/4"
Ø19 MM
5" 4-1/4" / 107.5 MM 3-13/16" / 96.1 MM
127 MM 4-1/2" / 114.3 MM 4-1/16" / 103 MM
SUB FOR: GREAT DANE 44573, SUB FOR: GREAT DANE 3190100, SUB FOR: TRAILMOBILE 515-12-13,
FLEET ENGINEERS 997-98015 FLEET ENGINEERS 997-98027 FLEET ENGINEERS 997-98016
1402 MATERIAL: FORGED STEEL MATERIAL: CARBON STEEL MATERIAL: CARBON STEEL
FINISH: ZINC-PLATED FINISH: ZINC-PLATED FINISH: ZINC-PLATED
WEIGHT: 0.17 LBS / 0.08 Kg WEIGHT: 0.29 LBS / 0.132 Kg WEIGHT: 0.372 LBS / 0.169 Kg
MODEL 1402-7545
I.D. 3/16" O.D. 5/8"
Ø4.1 MM Ø15.9 MM
4-1/8"
104.6 MM
4-7/16"
113 MM
SUB FOR: UTILITY 3-6101-071 & 3-6101-08,
FLEET ENGINEERS 997-98019
MATERIAL: FORGED STEEL
FINISH: ZINC-PLATED
WEIGHT: 0.47 LBS / 0.213 Kg
904-696-0010
E-mail: sales@buffersusa.com
1402-30 5/30/24
