1105-53
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

1-3/16" MODEL 1105-6387
30 MM
1/8" 13/16" for Rear Hi-Lo / Tank chassis
3 MM 20 MM
O.D. 2"
Ø51 MM I.D. 7/16" 1-11/16"
Ø11 MM 43 MM
3-11/16"
94 MM
9-1/8" 8-3/4"
231.8 MM 222.3 MM 2-1/4"
56 MM
1105
I.D. 1/2"
Ø12.7 MM

O.D. 1-1/2" FITS: CHASSIS KING MATERIAL: FORGED STEEL
Ø38 MM FINISH: PRIMER WEIGHT: 6.92 LBS / 3.14 Kg

MODEL 1105-6388
for Penz 90-02 series Twistlocks
2"
50.8 MM

3-7/8"
O.D. 2-1/4" 98.4 MM
Ø57.2 MM
5/8" 4-1/16" I.D. 3/8"
I.D. 9/16" 16 MM 103.2 MM 5-1/16" Ø10.3 MM 1-9/16" 2-1/4"
Ø15.1 MM 128.6 MM 39.4 MM 57.2 MM

O.D. 1-3/4"
Ø44.5 MM
SUB FOR: PENZ 15-85 FITS: PENZ 90-02-XX & 90-02-A-XX TWISTLOCKS
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.1 LBS / 2.77 Kg

MODEL 1105-6433
Kit includes loose parts shown: MODEL 1105-6433-KIT
1-3/16" for Holland Non-Retractable Twistlock
30 MM
Detent Spring
1/8"
3 MM 7-1/16" 3-11/16"
178.5 MM Detent Ball 94 MM
I.D. 1/4" 1" 5-3/4"
Ø6.4 MM 25.4 MM 148.5 MM 2-1/4"
I.D. 5/8" 5-3/16" Set Screw 56 MM
Ø16 MM 132 MM
Grease Fitting

O.D. 1-3/8" FITS: HOLLAND GL-726-099-195-GF NON-RETRACTABLE TWISTLOCK
Ø34.8 MM PIN MATERIAL: FORGED STEEL PIN FINISH: PRIMER
PIN WEIGHT: 3.75 LBS / 1.72 Kg

904-696-0010

E-mail: sales@buffersusa.com
1105-53 10/19/23
