1105-52
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-3817-2-LP
7/8"
22.3 MM 13/16" Low-Profile for Buffers 3817-LP Twistlocks
20 MM

3/8" 3/8"
10 MM 10 MM
3-11/16"
1/4" 94 MM
1/4"
6 MM 6 MM 6-13/16"
7-11/16" 172.5 MM
2-1/4"
195 MM 56 MM
I.D. 1/2"
Ø13 MM
1105
O.D. 1-1/2" FITS: BUFFERS 1101-3817-LP-L/R TWISTLOCKS
Ø38 MM WORKS WITH: 1107-3206-4 BENT HANDLE & 1108-3817-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.92 LBS / 2.23 Kg

MODEL 1105-3837-2
Low-Profile for Buffers 3837 & 3843
O.D. 2"
Ø51 MM 13/16" series Twistlocks
20 MM 1/32"
1 MM
I.D. 7/16" 3-11/16"
Ø11 MM 4-7/8" 94 MM
1-15/16" 124 MM
11/16"
I.D. 5/16" 18 MM 49 MM 5-5/8" I.D. 1/2" 2-1/4"
Ø8 MM 143.5 MM Ø13 MM 56 MM

O.D. 1-1/2"
Ø38 MM
FITS: BUFFERS 1101-3837-R/NR & 3843-R/NR TWISTLOCKS
WORKS WITH: 1107-8533-4 (straight) or 1107-8543-4 (bent) HANDLES & 1108-3633-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.77 LBS / 1.71 Kg

SPECIAL ORDER ONLY MODEL 1105-6386
for Flip-up / Tank chassis
1-3/16"
30 MM

3-11/16"
94 MM
I.D. 7/16"
Ø11 MM 1-3/4" 5-3/4" 2-1/4"
44.5 MM 146.1 MM 56 MM

O.D. 1-1/2"
Ø38 MM
FITS: CHASSIS KING MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.3 LBS / 1.95 Kg

904-696-0010

E-mail: sales@buffersusa.com
1105-52 10/19/23
