1105-49
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

1-3/16"
30 MM MODEL 1105-3529-2
1-11/16"
43 MM for Buffers 1101-3529 series
Screwdown Twistlocks
I.D. 7/16"
Ø11 MM
11/16" I.D. 5/32"
Ø8 MM
O.D. 1-1/2" 18 MM 3-11/16"
94 MM
Ø38 MM 7-1/4"
7-7/8"
199 MM 184.5 MM 2-1/4"
2-7/8" 56 MM
1-3/16" 72 MM
30 MM
I.D. 1/2"
Ø13 MM 1105
O.D. 1-1/4" FITS: BUFFERS 1101-3529 SERIES SCREWDOWN TWISTLOCKS
Ø31.5 MM WORKS WITH: 1110-3529-14 PIN NUT, BUFFERS 1107-3529-4 HANDLE,
1110-4531-G5 HEX BOLT & 1110-4511 HEX NUT MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.65 LBS / 2.11 Kg

MODEL 1105-3532-2
1-1/16" for Buffers 3532 series
27 MM
Retractable Twistlocks

I.D. 7/16" I.D. 5/16" 2-5/16" 3-7/8"
Ø11 MM 5/8" Ø7.9 MM 58.5 MM 97.5 MM
15 MM 5-7/8"
6-5/8" 150 MM 2-3/8"
168.5 MM I.D. 1/2" 59.5 MM
Ø13 MM

O.D. 1-1/2"
Ø38 MM FITS: BUFFERS 1101-3532 SERIES TWISTLOCKS
WORKS WITH: BUFFERS 1107-3133-4 & 1107-8533-4 STRAIGHT HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 5 LBS / 2.27 Kg

1105-3533-2 replaces 1105-3133-2 MODEL 1105-3533-2
1-3/16" SPECIAL ORDER ONLY MODEL 1105-3533-2-HDG
30 MM for Buffers 3100, 3500, 3600 & 3700
series Non-Screwdown Twistlocks
I.D. 5/16"
I.D. 7/16" Ø8 MM
Ø11 MM 11/16" 5-7/16" 3-11/16"
94 MM
18 MM 2" 138 MM
O.D. 1-1/2" 6-1/16" I.D. 1/2" 50.5 MM 2-1/4"
Ø38 MM 153 MM Ø13 MM 56 MM

FITS: BUFFERS 1101-3133-R/NR, 1101-3190-R/NR, 1101-3523-R/NR, 1101-3533-R/NR, 1101-3590-R/NR, 1101-3623-R/NR,
1101-3633-R/NR, 1101-3690-R/NR, 1101-3695-R/NR & 1101-3733-R & SCHULZ QA15NS TWISTLOCKS WORKS WITH: BUFFERS 1107-3133-4
& 1107-8533-4 STRAIGHT HANDLES, 1107-3533-4-OS70 & 1107-3533-4-OS127 EXTENDED HANDLES or 1107-3423-4, 1107-8543-4 & 1107-8723-4
BENT HANDLES, 1108-3133-18 & 1108-3633-18 LATCHES MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.28 LBS / 1.94 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-49 12/6/22
