TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-3534-2
1-3/16" for most Buffers 3500 & 3600 series
30 MM 1/16" Non-Retractable Twistlocks
1.5 MM
O.D. 2"
Ø51 MM 3-11/16"
94 MM
I.D. 7/16" 1-1/8" 5-1/4" 4-5/8"
Ø11 MM 28.5 MM 118 MM 2-1/4"
133.5 MM I.D. 1/2"
Ø13 MM 56 MM
1105
O.D. 1-1/2" FITS: BUFFERS 1101-3524-NR, 1101-3534-NR, 1101-3541-NR, 1101-3593-NR, 1101-3594-NR,
Ø38 MM 1101-3624-NR, 1101-3634-NR & 1101-3694-NR NON-RETRACTABLE TWISTLOCKS
WORKS WITH: BUFFERS 1107-3133-4 & 1107-8533-4 STRAIGHT HANDLES or
1107-3643-4 & 1107-8723-4 BENT HANDLES, 1108-3534-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.02 LBS / 1.82 Kg

MODEL 1105-3557-2
2" High Cone for Buffers 3262, 3557
50.8 MM & 3559 Drop-in Twistlocks
1/16"
1.5 MM 1"
26 MM
O.D. 2"
Ø51 MM 3-7/8"
I.D. 7/16" 2-13/16" 98.4 MM
4-7/16" Ø12 MM 71 MM
112 MM 5-1/16" 2-1/4"
I.D. 1/2" 129 MM 57.2 MM
Ø13 MM

O.D. 1-1/2"
Ø38 MM
FITS: BUFFERS 1102-3262-L/R, 1102-3557-L/R & 1102-3559-L/R TWISTLOCKS
WORKS WITH: BUFFERS 1107-1257-4, 1107-1259-4 & 1107-3260-4 HANDLES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 4.93 LBS / 2.23 Kg

1-7/16"
36 MM MODEL 1105-3600-2
2-3/16" for Height-Adjustable Twistlock
I.D. 7/16" 56 MM
Ø11 MM 7/8"
23 MM I.D. 5/16"
Ø8 MM
O.D. 4-1/4"
Ø108 MM
10-5/8"
11-7/16" 270.5 MM
290 MM 2-3/8"
61 MM
I.D. 1/2"
Ø13 MM
I.D. 1/2"
1-3/16" Ø13 MM
30 MM
FITS: 1101-3600-HA SERIES TWISTLOCKS WORKS WITH: 1107-3600-4 & 1107-3600-4-SQ T-HANDLES;
O.D. 1-5/8" 1107-3600-4-9 (older/round style) & 1107-3600-4-9-SQ (newer/sq. style) EXTENSION TUBES
Ø42 MM
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 9.4 LBS / 4.26 Kg
