1105-58
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-7400
for Pratt GN2040EZ chassis
1-7/8"
46.6 MM
1/16"
1.6 MM 1-3/8"
34.9 MM
O.D. 1-15/16" 3-11/16"
Ø49 MM 2-3/4" 94 MM
5-1/16" I.D. 7/16" 69.9 MM
128.6 MM Ø11.9 MM 2-3/16"
4-3/8" 55 MM
111.1 MM
1105 I.D. 1/2"
Ø12.7 MM
O.D. 1-1/2"
Ø38.1 MM
SUB FOR: PRATT 17414 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4.14 LBS / 1.88 Kg

MODEL 1105-7402
for Pratt chassis, short stem
1-13/16"
45 MM
1/16"
1.6 MM 1-3/8" 3-11/16"
34.9 MM 94 MM
O.D. 1-15/16"
Ø49 MM 2-5/8" 2-3/4" 2-3/16"
66.7 MM 3-3/16" I.D. 7/16" 69.9 MM 55 MM
81 MM
Ø11.9 MM
I.D. 1/2"
Ø12.7 MM
O.D. 1-1/2"
Ø38.1 MM
MATERIAL: FORGED STEEL FINISH: PRIMER
WEIGHT: 4.14 LBS / 1.88 Kg

MODEL 1105-7403
UNDRILLED, High Cone, 2" x 6"
2"
50.8 MM

3-7/8"
98.4 MM

6" 2-1/4"
152.4 MM 57.2 MM

O.D. 2"
Ø50.8 MM
SUB FOR: PENZ 15-144 MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 7.9 LBS / 3.58 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-58 10/19/23
