1105-47
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

MODEL 1105-3137-2
for Buffers 3136, 3137, 3637
7/8"
22.3 MM 1-11/16" & 3643 Twistlocks
42 MM
I.D. 7/16" I.D. 5/16" 3-11/16"
Ø11 MM Ø8 MM 94 MM
11/16" 4-13/16"
18 MM 122.3 MM
5-3/8" 2-1/4"
136.8 MM I.D. 1/2" 56 MM
Ø13 MM
1105
O.D. 1-1/2"
Ø38.1 MM FITS: BUFFERS 1101-3136 series, 1101-3137-R/NR, 1101-3637-R/NR & 1101-3643-R/NR TWISTLOCKS
WORKS WITH: BUFFERS 1107-3133-4 & 1107-8533-4 STRAIGHT HANDLES or 1107-3643-4
1107-8543-4 & 1107-8723-4 BENT HANDLES, 1108-3133-18 & 1108-3633-18 LATCHES
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.8 LBS / 1.72 Kg

SPECIAL ORDER ONLY MODEL 1105-3151-2
SPECIAL ORDER ONLY MODEL 1105-3151-2-HDG
3/4" for Buffers 3151 series & 3152 Twistlocks
19 MM
1-7/8"
47.5 MM
3-7/8"
I.D. 7/16" I.D. 5/16" 97.5 MM
Ø11 MM Ø7.9 MM 3-5/16"
5/8" 4-3/4" 84 MM
15 MM 120 MM 2-3/8"
I.D. 1/2" 59.5 MM
Ø13.2 MM
O.D. 1-1/2" FITS: BUFFERS 1101-3151 SERIES & 1101-3152 TWISTLOCKS
Ø38 MM
WORKS WITH: BUFFERS 1107-3151-4 HANDLE & 1108-3151-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER or HOT-DIP GALVANIZED
WEIGHT: 3.71 LBS / 1.68 Kg

MODEL 1105-3187-2
1-3/16"
30 MM for Max-Atlas chassis

1-3/4" 3-11/16"
I.D. 7/16" 45 MM 94 MM
Ø11 MM 1-1/8" I.D. 5/16"
29 MM Ø7.9 MM 5-3/4" 45º
146.5 MM
6-1/2" 2-1/4"
165 MM I.D. 1/2" 56 MM
Ø13 MM

O.D. 1-1/2"
Ø38 MM FITS: BUFFERS 1101-3187-R/NR TWISTLOCKS
WORKS WITH: BUFFERS 1107-3133-4, 1107-3187-4 & 1107-8533-4 HANDLES, 1108-3187-18 LATCH
MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 3.9 LBS / 1.77 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-47 3/9/23
