1105-43
[return to Table of Contents]
TWISTLOCK PINS

CHASSIS | FLATBED TRAILERS

2" MODEL 1105-2853
50.8 MM
for Maersk chassis

O.D. 2-1/16"
Ø52 MM 3-7/8"
1/4"
6.4 MM 98.4 MM
I.D. 3/4" 6-1/4"
Ø19.5 MM 158.8 MM 2-1/4"
57.2 MM
4-1/8"
104.8 MM
1105
O.D. 1-3/4"
Ø44.5 MM
SUB FOR: PENZ 15-134 WORKS WITH: BUFFERS 1107-1394 HANDLE
COMPARE AGAINST paired w/ 1110-2477 CLEVIS BOLT + 1110-4551-SS COTTER PINS (2 pcs.)
PIN 1105-2476 MATERIAL: FORGED STEEL FINISH: PRIMER WEIGHT: 6.7 LBS / 3.04 Kg

SPECIAL ORDER ONLY MODEL 1105-2881-L
SPECIAL ORDER ONLY MODEL 1105-2881-R
for Utility chassis
1-9/16"
39.7 MM 1105-2881-L 1105-2881-R
3-7/8"
98.4 MM
45º
I.D. 5/8" 3-1/8" 3-7/8"
Ø16.7 MM 79.4 MM 98.4 MM 2-1/4"
57 MM

O.D. 1-3/8"
Ø34.9 MM
SUB FOR: PENZ 15-29-A-XX MATERIAL: FORGED STEEL
FINISH: PRIMER WEIGHT: 4 LBS / 1.81 Kg

2" MODEL 1105-2882
50.8 MM
1/16"
1.6 MM
O.D. 2-1/4"
Ø57.2 MM 3-7/8"
98.4 MM
I.D. 3/8" 1-5/16"
Ø10.3 MM 33.3 MM
6-15/16" 2-1/4"
176.2 MM 57 MM
7-1/2"
190.5 MM
I.D. 1/2"
Ø13.5 MM
O.D. 1-1/2" SUB FOR: PENZ 15-146F MATERIAL: FORGED STEEL
Ø38.1 MM
FINISH: PRIMER WEIGHT: 6.02 LBS / 2.73 Kg

904-696-0010
E-mail: sales@buffersusa.com
1105-43 3/9/23
