P. 16
1001-02
[return to Table of Contents]
SAND SHOES – LOW-PROFILE
CHASSIS & TRAILERS:
AUTO / DRY VAN / FLATBED / REEFER VAN
MODEL 1001-6476
No Gusset
I.D. 2"
I.D. 7/16" Ø51 MM 1/4" Sides
Ø12 MM 3/16" Base
1001
12"
1-3/4"
12" SUB FOR: PENZ 05-321 FINISH: PRIMER WEIGHT: 11 LBS / 4.9 Kg
SPECIAL ORDER ONLY MODEL 1001-6493
HEAVY DUTY
I.D. 7/16" I.D. 2" No Gusset
Ø11.6 MM Ø50.8 MM 1/4" Patch
1/4" Sides
12" 1/4" Base
1-3/4"
10" SUB FOR: PENZ 05-308 FINISH: PRIMER WEIGHT: 13 LBS / 5.9 Kg
MODEL 1001-6494
I.D. 2" No Gusset
I.D. 7/16" Ø50.6 MM 3/16" Patch
Ø11.7 MM
3/16" Sides
3/16" Base
12"
305 MM 2-3/16"
56 MM
10" SUB FOR: PENZ 05-329 FINISH: PRIMER WEIGHT: 10.4 LBS / 4.7 Kg
254 MM
904-696-0010
E-mail: sales@buffersusa.com
1001-2 4/3/19
