5010-02

BRIDGE FITTINGS

MODEL 5010-C7

260 MM
10-1/4"
43 MM
12 MM 1-11/16" ADJUSTABLE RANGE
15/32"
179 MM – 259 MM
7-1/16" – 10-3/16"

M27x3 M27x3 116 MM
L.H.T. R.H.T. 4-9/16"

0 MM – 80 MM
0" – 3-15/32"

WRENCH: USE 5010-C7-WR MIN. B.L. TENSION: 7 M. TON
MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED (HDG) WEIGHT: 2.72 Kg / 6.75 LBS

MODEL 5010-C7-1

280 MM ADJUSTABLE RANGE
5010 11-1/32" 179 MM – 259 MM
15 MM 7-1/16" – 10-3/16"
19/32"

0 MM – 100 MM
0" – 3-15/16"
M34x4 M34x4 WRENCH: USE 5010-C7-WR
L.H.T. R.H.T.
MIN. B.L. TENSION: 10 M. TON
MATERIAL: STEEL
FINISH: HOT-DIP GALVANIZED (HDG)
WEIGHT: 3.97 Kg / 8.75 LBS

320 MM / 12-5/8" SPECIAL ORDER ONLY MODEL 5010-6951
68 MM
2-11/16"

TR38x7 TR38x7
L.H.T. 50 MM R.H.T. WRENCH: USE 5010-C7-WR
1-15/16" MIN. B.L. TENSION: 15 M. TON
MATERIAL: STEEL
MIN. 104 MM / 4-1/8" FINISH: HOT-DIP GALVANIZED (HDG)
MAX. 310 MM / 12-3/16" 130.5 MM WEIGHT: 7.37 Kg / 16.25 LBS
5-1/8"

®
904-696-0010
E-mail: sales@buffersusa.com
5010-2 9/14/23
