5010-01

BRIDGE FITTINGS

TENSION TYPE

5010-C7 5010-C7-1

5010-C7-WR

TENSION /
MODEL COMPRESSION ADJUSTABLE CONTAINER SIZE WEIGHT
MIN. BREAKING LOAD RANGE DISTANCE
(M. TON) (MM) (MM) A B
5010-C7 7.0 179 – 259 0 – 80 – – 3.5 Kg / 7.7 LBS 5010

5010-C7-1 10.0 179 – 290 0 – 100 – – 4.6 Kg / 10.1 LBS
5010-6951 15.0 104 – 310 0 – 200 – – 7.40 Kg / 16.3 LBS

5010-C7-WR – – – M41 M52 0.9 Kg / 1.9 LBS

5010-C7 5010-C7-1
179 MM – 259 MM 179 MM – 290 MM
7-1/16" – 10-3/16" 7-1/16" – 11-7/16"

0 MM – 80 MM 0 MM – 100 MM
0" – 3-1/8" 0" – 3-15/16"
WRENCH
5010-C7-WR

B A
MATERIAL: FORGED STEEL
FINISH: HOT-DIP GALVANIZED (HDG)
250 MM CLASS-APPROVED
10"

904-696-0010
E-mail: sales@buffersusa.com
5010-1 6/1/21
