P. 175
5009-08
LASHING BARS
MAERSK / ARNE HOLST MODELS
KNOB TYPE
2-KNOB TYPE w/ HINGED HEAD
APM-2100-00/1
Ø25 MM Swage Rod Head
O.D. 1"
20 MM
13/16"
Red color marking Swage
15 MM 220 MM
5/8" 8-11/16"
78 MM
A 3-1/8"
Ø38 MM
48 MM
O.D. 1-1/2" 1-15/16"
MIN. B.L.
MODEL APM # (M. Ton) A WEIGHT
5009-LB-2085-K2S
SPECIAL ORDER ONLY 357388/355284 48 2,085 MM / 82-1/8" 11 Kg / 24.3 LBS
5009
3-KNOB TYPE w/ HINGED HEAD
APM-2100-00/1
Ø25 MM Swage Rod Head
O.D. 1"
20 MM
13/16"
Swage
15 MM 230 MM 215 MM
5/8" 9-1/16" 8-7/16"
78 MM
A 3-1/8"
Ø38 MM
O.D. 1-1/2" 48 MM
1-15/16"
MIN. B.L.
MODEL APM # (M. Ton) A WEIGHT
5009-LB-2520-K3S 360779/342417 48 2,520 MM / 99-1/4" 13.1 Kg / 28.9 LBS
5009-LB-2650-K3S 1938583 48 2,650 MM / 104-3/8" 13.7 Kg / 30.2 LBS
SPECIAL ORDER ONLY
904-696-0010
E-mail: sales@buffersusa.com
5009-8 12/12/22
