P. 25
1201-11
[return to Table of Contents]
FRONT PANELS
ISO CONTAINERS
4-5/16" MODEL 1201-2230
110 MM
11/16" 11/16" FRONT PANEL, High Cube
40-9/16" x 106-5/16" x 2 MM
18 MM 18 MM 9-13/16"
250 MM
1-3/4" 1201
45 MM
2-5/16" 4-1/8" 3"
58 MM 104 MM 76 MM
40-9/16"
1,030 MM
SUB FOR: CSP-13-HC THICKNESS: 5/64" / 2 MM LENGTH: 106-5/16" / 2,700 MM
MATERIAL: CORTEN STEEL FINISH: PRIMER WEIGHT: 110 LBS / 49.9 Kg
904-696-0010
E-mail: sales@buffersusa.com
1201-11 9/25/19
