Page 27 - Buffers USA 2024 Container Hardware Catalog FlipBook
P. 27
1201-13
[return to Table of Contents]
SIDE PANELS
ISO CONTAINERS
2-13/16" MODEL 1201-6399
72 MM SIDE PANEL, High Cube
2-11/16" 2-11/16" 106-3/8" x 44" x 1.6 MM
68 MM 68 MM
1-7/16" 1201
36 MM
1-7/16" 2-3/4" 10-15/16" 1-7/16"
37 MM 70 MM 278 MM 37 MM
44"
1,117 MM
SUB FOR: BUFFERS 1201-2819 THICKNESS: 1/16" / 1.6 MM LENGTH: 106-3/8" / 2,700 MM
MATERIAL: CORTEN STEEL FINISH: PRIMER WEIGHT: 83 LBS / 37.6 Kg
