1201-06
[return to Table of Contents]
SIDE PANELS

DOMCON CONTAINERS

MODEL 1201-6886
3-15/16" MAIN SIDE PANEL
100 MM for Jindo / J.B. Hunt & Schneider 53'
3/16" 3/16" 8-5/16" 5 Corrugation, 41-9/16" x 96-15/16"
1201 5 MM 5 MM 211 MM

2" 4" 2"
51 MM 101 MM SECTION A-A 51 MM 3/4"
41-9/16" 19 MM 5/8"
1,056 MM 16.5 MM

2-7/8"
73 MM

97"
2,462 MM
3/4"
19 MM
A A
2-7/8"
73 MM
5/8"
16.5 MM

SUB FOR: JINDO AH0401-9280 & AH0401-9530 FITS: J.B. HUNT & SCHNEIDER 53' THICKNESS: 3/64" / 1.1 MM
LENGTH: 96-15/16" / 2,462 MM MATERIAL: DOCOL (H.S. STEEL) FINISH: PRIMER WEIGHT: 54.1 LBS / 24.54 Kg

MODEL 1201-7389
3-7/8"
98 MM MAIN SIDE PANEL for CIMC/Hub/
3/16" 3/16" 8-3/8" J.B. Hunt/Singamas 53'
5 MM 5 MM 213 MM 5 Corrugation
11/16" 41-15/16" x 97-1/16"
17 MM 2-1/16" 4-1/8" 2-1/16"
53 MM 105 MM 41-15/16" 53 MM
1,066 MM

SUB FOR: HUB QPJH-600020; JBH QP-53DJH-1; NAVISTAR 9310-002C, 9320-002C & 9330-002C; SINGAMAS 53-500002
FITS: CIMC, HUB, J.B. HUNT & SINGAMAS 53' THICKNESS: 1/16" / 1.6 MM LENGTH: 97-1/16" / 2,465 MM
MATERIAL: CORTEN STEEL FINISH: PRIMER WEIGHT: 78.2 LBS / 35.5 Kg

MODEL 1201-7916
3-15/16"
100 MM STARTER SIDE PANEL for CIMC 53'
3/8" 3/8" 5 Corrugation, 41-9/16" x 98-3/4"
8-7/16"
10 MM 10 MM 214 MM
13/16" 13/16"
20.5 MM 1-9/16" 3-11/16" 1-9/16" 20.5 MM
39.5 MM 94 MM 39.5 MM
41-9/16"
1,055 MM

SUB FOR: CIMC AD53-0302E-26-L, JBH 18554 & VANGUARD CDAD53-0302E-26 FITS: CIMC 53' THICKNESS: 1/16" / 1.6 MM
LENGTH: 98-3/4" / 2,508 MM MATERIAL: CORTEN STEEL FINISH: PRIMER WEIGHT: 79.4 LBS / 36.02 Kg

904-696-0010
E-mail: sales@buffersusa.com
1201-6 10/28/21
