SWING DOOR HARDWARE
HOLDBACKS
CONTAINERS: DOMCON, ISO & REEFER
TRAILERS: DRY & REEFER VAN

KIT w/ all 3 items (2" loop shown) HOLDBACK HOOK LOOP MODEL 1402-7219-A-HDG
1402-7219-KIT-2-HDG 1402-7219-A-HDG (6" shown)
1402-7219-C-6-HDG HOLDBACK HOOK w/ 5" ARM
& 2-HOLE BRACKET
11/16" O.D. 5/16"
18 MM Ø8 MM MODEL 1402-7219-B-HDG
FOOTMAN LOOP ANCHOR / HANDLE
6-3/8"
161.9 MM MODEL 1402-7219-C-2-HDG
I.D. 1/4" 3/16"
Ø6.8 MM 5 MM MODEL 1402-7219-C-4-HDG
x 2 HOLES 1-1/4"
31.8 MM 6" WELDED MODEL 1402-7219-C-6-HDG
152.4 MM
LOOP (3 lengths available)
2"
1402 FOOTMAN LOOP ANCHOR 50.8 MM 1-5/16" MODEL 1402-7219-KIT-2-HDG
1402-7219-B-HDG 33.5 MM MODEL 1402-7219-KIT-4-HDG
3"
5" 76.2 MM
127 MM MODEL 1402-7219-KIT-6-HDG
1-3/8" KIT ASSEMBLIES (3 diff. loop lengths)
2-1/4" 34 MM
58 MM
3/16"
4.5 MM
EACH PACKAGED DOOR HOLDBACK SET INCLUDES:
• (A) Holdback Hook w/ 5" arm and
2-hole bracket (1402-7219-A-HDG)
• (B) Footman Loop Anchor (1402-7219-B-HDG) MATERIAL: STEEL FINISH: HOT-DIP GALVANIZED
ASSEMBLY WEIGHT (6"): 0.83 LBS / 0.376 Kg
• (C) Loop (3 lengths available: 2", 4", 6")

MODEL 1402-7254-KIT I.D. 5/8" MODEL 1402-7438
Ø16 MM
VENT DOOR HOLDBACK KIT consists of: HOLDBACK CHAIN
7254-1 HOLDBACK CUP (Female)
7254-2 PEG (Male)
O.D. 15/16"
Ø24.3 MM
O.D. 11/16"
Ø16.5 MM I.D. 1/4"
7/16" Ø6.6 MM
11.5 MM thru hole
1-1/16"
26.7 MM
1/2" 1/4"
13.3 MM 6 MM
13"
330 MM
O.D. 11/16"
Ø17.5 MM
O.D. 1"
Ø25 MM
I.D. 1/4"
Ø6.6 MM SECTION A-A
thru hole
A A
7/8" / 22 MM 7254-2 HOLDBACK PEG
flat to flat TYP Male 7/16" / 11.6 MM 1/4"
flat to flat TYP
6.4 MM
HOLDBACK CUP MATERIAL:
RUBBER w/ GALV. STEEL PLATE O.D. 5/32" MATERIAL: FAB. STEEL
Ø4 MM
PEG MATERIAL: NYLON (PA66) COLOR: BLACK 1-3/16" FINISH: HOT-DIP GALVANIZED
KIT WEIGHT: 0.16 LBS / 0.07 Kg 30 MM WEIGHT: 0.16 LBS / 0.07 Kg
